The Honeywell DC-PDIL51 (51454818-175) is a precision Pulse Duration Input Module engineered for Experion PKS C300 controllers. It accurately captures high-speed digital pulse signals, making it ideal for applications such as turbine flow meters, tachometers, and other time-based process measurements. Each input channel is isolated to ensure reliable performance in electrically noisy environments, and the module supports redundancy for critical process control.
Technical Specifications
| Specification |
Details |
| Input Channels |
8 isolated channels |
| Signal Type |
Discrete pulse duration input |
| Input Voltage Range |
15–30 VDC |
| Isolation |
Channel-to-channel and channel-to-bus isolation |
| Scan Speed |
≤ 1 ms per channel typical |
| Response Time |
≤ 2 ms |
| Operating Temperature |
-40°C to +70°C |
| Storage Temperature |
-40°C to +85°C |
| Relative Humidity |
5% to 95% non-condensing |
| Dimensions (W×H×D) |
63.5 × 124.46 × 307.34 mm |
| Weight |
0.5 kg |
| Mounting |
C-Series chassis slot |
| Redundancy |
Supported via redundant I/O configuration |
| Certifications |
CE, CSA, UL, ATEX compliant |
| Power Consumption |
~10 mA per channel |
Key Features & Advantages
-
High-Speed Pulse Capture: Ideal for precise measurement of fast digital signals from flow meters, tachometers, and other field devices.
-
Robust Isolation: Ensures reliable operation in environments with electrical noise.
-
Redundancy Support: Enhances system reliability in critical applications.
-
Seamless Integration: Fully compatible with Honeywell Experion PKS C300 controllers.
-
Built-In Diagnostics: Simplifies troubleshooting and maintenance.
Applications
-
Turbine and flow meter monitoring
-
Tachometer signal acquisition
-
Time-based process measurement in continuous operations
-
Critical control loops requiring fast, isolated pulse inputs
FAQ
Q: Can this module be used with non-Honeywell controllers?
A: The module is optimized for Experion PKS C300 controllers; use outside this ecosystem may limit functionality.
Q: How fast can the module detect pulse signals?
A: Scan speed is ≤ 1 ms per channel with response time ≤ 2 ms, suitable for high-speed process signals.
Q: How many channels support isolated pulse inputs?
A: All 8 channels provide full isolation for reliable signal capture.
Q: Are there similar modules in the Experion Series-C family?
A: Yes, modules like DC-PDIL50 offer fewer channels or lower-speed capture, while DC-PDIL51 provides 8-channel high-speed input for precise measurement.
