Description

Overview

The CC-PWRB01 C300 Series Power Supply from Honeywell is a redundant power system designed to deliver stable +24 VDC output for distributed control system (DCS) applications. Built for the Experion PKS platform, it ensures uninterrupted operation by combining dual power supplies with integrated battery backup capability.

Technical Specifications

• Model: CC-PWRB01

• Manufacturer: Honeywell

• Product Type: C300 Series Power Supply

• Condition: Brand New

• Availability: In Stock

• Weight: 0.4 kg

• Dimensions: 19.1 × 18.8 × 6.5 cm

• HS Code: 8537101190

• Minimum Order Quantity: 1

• Origin: USA (global distribution from Xiamen, China)

• System Compatibility: DCS / Experion PKS

• Output Voltage: +24 VDC

• Output Current: 20 A per supply

• Redundancy: Dual 24 VDC supplies for continuous operation

• Backup Assembly: Rechargeable battery and charger, supports 30 minutes of backup power

• Input Sources: Independent AC line or UPS connection

• Output Voltage Range:

• AC input: 25–26 VDC at 20 A

• Battery backup: 24–25 VDC at 20 A

• Enclosure: Metal housing with eight-connector interface

• Distribution Ports: Six 24 VDC connectors, one controller memory backup connector, one alarm contact connector

Functional Highlights

• Dual redundant supplies ensure continuous operation during power source failure.

• Integrated battery backup maintains output for up to 30 minutes during AC outages.

• Flexible input options allow connection to separate AC or UPS sources.

• Compact enclosure simplifies installation and supports efficient cabinet integration.

• Eight-connector interface provides streamlined distribution and monitoring.

Application Scenarios

• Power generation facilities requiring redundant supply systems.

• Oil & gas plants with critical process control needs.

• Chemical processing environments demanding reliable backup capability.

• Industrial automation systems where uninterrupted power delivery is essential.

FAQ

Q: How long does the CC-PWRB01 provide backup power?  A: Up to 30 minutes using the integrated rechargeable battery assembly.

Q: Can the module operate with separate AC sources?  A: Yes, each supply can be powered independently from an AC line or UPS.

Q: What is the maximum current output per supply?  A: Each supply delivers 20 amperes at +24 VDC.

Q: Is the CC-PWRB01 compatible with Experion PKS controllers?  A: Yes, it is fully designed for Honeywell’s Experion PKS C300 systems.

Specifications

• Dimensions: 19.1 × 18.8 × 6.5 cm
• Brand: Honeywell

Advantages

• High reliability in industrial environments
• Supports continuous operation
• Compatible with major PLC/DCS systems
