The CC-PDIS01 51405042-176 from Honeywell is a high-performance digital input module designed for Safety Manager systems. With 32 input channels supporting 24 VDC discrete signals, it delivers precise monitoring and event sequencing capabilities. Built for demanding industrial environments, this module ensures accurate signal acquisition, robust diagnostics, and reliable integration into distributed control systems (DCS).

Technical Specifications

• Model Number: CC-PDIS01

• Part Number: 51405042-176

• Manufacturer: Honeywell

• Product Type: Digital Input Module

• System Compatibility: Safety Manager / DCS Systems

• Condition: Brand New

• Weight: 0.4 kg

• Dimensions: 24 × 18.8 × 6.5 cm

• HS Code: 8537101190

• Origin: USA

• Lead Time: In Stock

• Minimum Order Quantity (MOQ): 1

• Status: Discontinued (Dec 31, 2018)

Electrical and Functional Characteristics

• Input Channels: 32 isolated digital inputs

• Input Voltage Range: 18–30 VDC

• ON Sense: ≥ 13 VDC or ≥ 3 mA

• OFF Sense: ≤ 5 VDC or ≤ 1.2 mA

• Operating Modes:

• Normal: 20 ms PV scan

• Sequence of Events (SOE): 1 ms resolution

• Low Latency: 5 ms PV scan

• Diagnostics: Open-wire detection, data integrity checks

• Redundancy: Optional redundant configuration supported

• Field Power: Internal/external selection with onboard excitation power

• Safety: Non-incendive field power, galvanic isolation

Functional Highlights

• Provides accurate event sequencing with 1 ms resolution.

• Built-in diagnostics prevent false inputs and ensure data integrity.

• Supports redundancy for high availability in critical systems.

• Compact design with flexible field power options.

• Suitable for safety-critical applications requiring precise monitoring.

Application Scenarios

• Process industries requiring event sequencing and digital input monitoring.

• Safety-critical systems in oil, gas, and chemical plants.

• Manufacturing facilities needing reliable input acquisition.

• Power generation and utility systems requiring redundancy and diagnostics.

FAQ

Q: How many input channels does the CC-PDIS01 provide?  A: It offers 32 isolated digital input channels.

Q: What is the resolution for Sequence of Events recording?  A: 1 ms resolution for precise event tracking.

Q: Does the module support redundancy?  A: Yes, optional redundancy is available for high-availability configurations.

Q: How does it compare to CC-PDIL01?  A: The CC-PDIS01 provides advanced diagnostics and SOE recording, while CC-PDIL01 is optimized for low-latency input scanning.
