Description
Overview
The CC-PAIH51 51410069-275 Analog Input Module from Honeywell is a precision-engineered unit designed for the Experion PKS platform. With 16 input channels and advanced 16-bit A/D conversion, it ensures accurate and rapid signal acquisition for demanding industrial control environments. Compact and lightweight, this module is optimized for both new installations and retrofit projects where reliability and performance are critical.
Technical Specifications
-
Model: CC-PAIH51 51410069-275
-
Manufacturer: Honeywell
-
Product Type: Analog Input Module
-
Condition: Brand New
-
Availability: In Stock
-
Weight: 0.4 kg
-
Dimensions: 5.5 × 16 × 14.5 cm
-
HS Code: 8537101190
-
Minimum Order Quantity: 1
-
Origin: USA
-
System Compatibility: DCS / Experion PKS
-
Input Channels: 16
-
Resolution: 16-bit A/D conversion
-
Input Range: 4–20 mA via 200 Ω resistor
-
Scan Rate: 50 ms
-
Diagnostics: Built-in self-diagnostics with redundancy support
-
Communication: HART protocol capable
-
Power Supply: Provides non-incendive power directly to field devices
-
Signal Integrity: Common mode rejection 70 dB, crosstalk suppression -60 dB
-
Communication Service: Ethernet router
Functional Highlights
-
High-speed input scanning for dynamic process environments.
-
HART-enabled for configuration and monitoring of multivariable instruments.
-
Supplies safe power directly to field devices, reducing external wiring needs.
-
Strong signal integrity with advanced noise rejection and isolation.
-
Optional redundancy for maximum uptime in mission-critical applications.
Application Scenarios
-
Oil & gas operations requiring precise analog input monitoring.
-
Power generation facilities with high-speed process control needs.
-
Chemical plants demanding robust diagnostics and redundancy.
-
Hazardous environments where non-incendive power supply enhances safety.
FAQ
Q: How many channels does the CC-PAIH51 support? A: It supports 16 analog input channels with 16-bit resolution.
Q: Does the module provide redundancy? A: Yes, optional redundancy is available to maximize system uptime.
Q: Can the CC-PAIH51 integrate with HART devices? A: Yes, it is fully HART-capable for configuration and diagnostics.
Q: What makes this module suitable for hazardous environments? A: It supplies non-incendive power directly to field devices, reducing risk and simplifying installation.
