Description

Honeywell CC-KFSGR5 Grounding Cable Assembly

Configured for signal grounding and electromagnetic interference mitigation in Honeywell Experion PKS C300 / Fieldbus Interface Module (FIM) subsystems, the Honeywell CC-KFSGR5 (51202353-201) provides direct electrical bonding and noise suppression within field communication grounding networks.

The assembly functions as a dedicated grounding and filtering interface element between controller-side termination structures and fieldbus network grounding references. It is designed to maintain controlled impedance grounding paths for industrial communication buses, reducing susceptibility to conducted and radiated electrical noise within C300/FIM chassis interconnect environments.

Suffix Breakdown & Model Matrix

No formally published suffix decomposition or functional segmentation for CC-KFSGR5 (51202353-201) is defined in Honeywell public hardware documentation. The part number is treated as a single-order assembly identifier without documented modular suffix logic.

Hardware Specifications

Parameter	Specification
Model	CC-KFSGR5 (51202353-201)
Brand	Honeywell
Origin	USA / Mexico (manufacturing dependent on production batch)
Weight	0.2kg
Dimensions	Not specified
Operating Temp	Not specified (system-level C300/FIM environmental limits apply)
Power Consumption	Passive component, no electrical load
Component Type	Grounding Cable / Filter Assembly
System Compatibility	Experion PKS C300 Controller / FIM modules
Function	Ground bonding, EMI reduction, noise suppression
Signal Domain	Fieldbus grounding reference path

FOUNDATION Fieldbus Grounding Architecture Behavior

Within Honeywell Experion PKS architectures, CC-KFSGR5 participates in controlled grounding topology for FOUNDATION Fieldbus segments. The assembly supports stable reference potential distribution between FIM termination structures and cabinet grounding rails, minimizing differential noise accumulation across communication conductors.

Channel-level isolation is implemented at system architecture level via FIM and controller backplane design, while CC-KFSGR5 contributes through low-impedance grounding continuity. This prevents floating potential drift between segment shields and cabinet earth reference points under high-frequency switching interference conditions typical of distributed I/O environments.

Frequently Asked Questions (FAQ)

Q: Does CC-KFSGR5 carry active signal current?
A: No. The component is passive and is intended only for grounding continuity and EMI path control. It does not conduct process signals or loop power.

Q: Is the assembly hot-swappable within the C300/FIM chassis?
A: It is not classified as a hot-swappable module. Installation or removal should be performed under system power-down conditions or according to cabinet grounding safety procedures.

Q: Does it influence backplane communication timing?
A: No direct impact on backplane bus timing exists. Its function is limited to grounding reference stabilization and noise attenuation.

Field Installation Guidelines

The grounding assembly shall be installed with direct mechanical bonding to the designated chassis grounding interface point within the FIM/C300 cabinet structure. Shield continuity must be maintained without interruption across termination points. Routing shall avoid parallel alignment with high-frequency switching conductors or variable-speed drive cabling.

Ground termination resistance should be kept as low as practical using approved cabinet earth bonding practices. Cable strain relief must be applied to prevent mechanical stress on connector interfaces. Installation must ensure no floating shield segments exist between fieldbus segment termination and cabinet ground reference.

Specifications

• Brand: Honeywell

Advantages

• High reliability in industrial environments
• Supports continuous operation
• Compatible with major PLC/DCS systems
