Honeywell 900TEK-0200 Terminal Block Housing

The Honeywell 900TEK-0200, also cataloged as the 900TEK-0200 Terminal Block Housing, operates as a dedicated terminal connection component for low voltage signal wiring within Honeywell ControlEdge HC900 I/O systems.

Hardware Specifications

Parameter	Specification
Model	900TEK-0200
Brand	Honeywell
Product Type	Terminal Block Housing
Origin	USA
Weight	0.1 kg
Dimensions	13.4 x 3.5 x 5.4 cm
Operating Temp	Not specified by manufacturer
Power Consumption	Passive terminal component, no external power consumption
Terminal Type	Low Voltage Terminal Block
Terminal Quantity	20 channels
Terminal Style	Euro style
Wire Gauge Range	Barrier and Euro: #14 to 26 AWG, solid or stranded
Contact Style	Post and socket
Terminal Color	Black
High Voltage Terminal Color	Red
High Voltage Contacts	Tin coated
Low Voltage Contacts	Gold plated
Door Access	Tool accessible
Tariff Code	8537101190
Place of Shipment	Xiamen, China

Channel Isolation and Process Wiring Interface

The Honeywell 900TEK-0200 provides a physical termination interface for low voltage field wiring connections. The terminal block uses post and socket contact construction to maintain mechanical alignment between wiring terminals and connected I/O assemblies.

For Honeywell process control installations, terminal assemblies support structured field signal routing. Therefore, correct separation between low voltage signal conductors and high voltage wiring paths must be maintained during installation. The gold plated low voltage contacts reduce contact oxidation effects, while tin coated high voltage contacts support standard electrical termination practices.

Frequently Asked Questions

Q: What type of wiring does the Honeywell 900TEK-0200 support?
A: The terminal block supports solid or stranded conductors from #14 to 26 AWG for barrier and Euro style wiring connections.

Q: Does the Honeywell 900TEK-0200 require external power?
A: No. The 900TEK-0200 functions as a passive terminal connection component and does not consume operating power.

Q: What access method is used for the terminal connections?
A: The terminal block uses tool accessible connections to prevent unintended field adjustments during operation.

Field Installation Guidelines

• Install the Honeywell 900TEK-0200 according to the HC900 system hardware installation documentation.
• Verify that field wiring matches the required terminal assignment before applying system power.
• Separate low voltage signal wiring from high voltage conductors to reduce electrical interference.
• Use compatible wire gauges within the specified #14 to 26 AWG range.
• Confirm terminal contact surfaces remain clean before completing the post and socket connection.
• Apply proper cable routing and strain relief methods to prevent mechanical stress on terminal connections.
• Inspect wiring polarity and termination points during commissioning procedures.
