Description
Overview
The 8C-TPOX01 51307022-175 Wireless Module Backplane from Honeywell is a precision-engineered component within the Series 8 product line. Designed for distributed control systems (DCS), it provides high-performance signal acquisition and communication capabilities, ensuring reliable integration of temperature and process monitoring sensors in demanding industrial environments.
Technical Specifications
-
Model Number / Part Number: 8C-TPOX01 51307022-175
-
Manufacturer: Honeywell
-
Module Type: Wireless Module Backplane
-
Condition: Brand New
-
System Compatibility: Honeywell Series 8 DCS, PLC platforms
-
Product Range: Series 8
-
Dimensions: 14.5 cm × 12 cm × 5.5 cm
-
Weight: 0.16 kg
-
HS Code: 8537101190
-
Origin: USA
-
Minimum Order Quantity (MOQ): 1
-
Lead Time: In Stock
-
Status: Active
-
Communication Interface: Ethernet router, supports HART 7 and Modbus RTU protocols
-
Safety & Compliance: IEC 61326 (EMC), IEC 61010-1 (safety)
-
Design Features: Hot-swappable, galvanic isolation (500V), LED diagnostics
Functional Highlights
-
Supports multiple sensor types: RTDs (Pt100/Pt1000), thermocouples (J/K/T), and millivolt inputs
-
±0.1°C measurement accuracy across four configurable channels
-
50 ms update rate for real-time process monitoring
-
Dual-protocol communication for integration with smart sensors and automation networks
-
Wide operating range: -40°C to +85°C, 95% non-condensing humidity tolerance
-
Advanced diagnostics: broken wire detection, out-of-range alerts, drift compensation
-
DIN-rail mountable with removable terminal blocks for simplified installation and maintenance
-
MTBF rating of 500,000 hours for long-term reliability
Application Scenarios
-
Pharmaceutical manufacturing requiring precise thermal monitoring
-
Food processing plants with strict temperature control standards
-
Energy sector installations exposed to harsh outdoor conditions
-
Industry 4.0 environments needing predictive maintenance and sensor performance logging
FAQ
Q: What sensor types are supported? A: The 8C-TPOX01 51307022-175 supports RTDs, thermocouples, and millivolt input sensors.
Q: Can the module be installed outdoors? A: Yes, it operates reliably in unheated enclosures with wide temperature and humidity tolerance.
Q: How does it support predictive maintenance? A: Embedded trend logging tracks sensor performance and temperature profiles for proactive maintenance.
