Description
Overview
The 8C-TDODB1 Digital Output Module from Honeywell is part of the Series 8 platform, engineered to deliver reliable 24 VDC output control for distributed control systems (DCS). Designed with a compact, integrated architecture, this module combines electronics and field terminations into one unit, reducing the need for external chassis and simplifying installation.
Technical Specifications
| Parameter |
Value |
| Model Number |
8C-TDODB1 |
| Product Type |
Digital Output Module |
| Manufacturer |
Honeywell |
| Condition |
Brand New |
| Product Range |
Series 8 |
| System Compatibility |
DCS / Experion PKS |
| Dimensions |
29.4 × 12 × 6.3 cm |
| Weight |
0.42 kg |
| HS Code |
8537101190 |
| Origin |
USA |
| Minimum Order Quantity |
1 |
| Lead Time |
In Stock |
| Lifecycle Status |
Active |
| Output Channels |
16 digital outputs |
| Output Voltage |
24 VDC |
| Terminal Design |
Two-level detachable terminals for simplified wiring |
| Redundancy |
Supported via IOTA base without external cabling |
| Environmental Protection |
Conformal coating option (8C prefix) for moisture, dust, and chemical resistance |
| Mounting |
DIN-rail / IOTA base integration |
| Communication Service |
Ethernet Router |
Key Features
-
16-channel digital output module for reliable 24 VDC control
-
Integrated field power distribution via IOTA base, eliminating extra power supplies
-
Two-level detachable terminal design for easier wiring and maintenance
-
Compact architecture saves cabinet space and simplifies installation
-
Supports redundancy without external cabling for fault-tolerant operation
-
Available in coated (8C) and uncoated (8U) versions for environmental adaptability
-
Rugged construction suitable for harsh industrial conditions
Application Scenarios
-
Oil and gas facilities requiring dependable digital output control
-
Chemical processing plants with limited cabinet space
-
Power generation sites needing redundant output modules
-
Experion PKS installations where simplified wiring and robust performance are critical
FAQ
Q: How many output channels does the 8C-TDODB1 provide? A: It supports 16 digital output channels at 24 VDC.
Q: What is the advantage of the detachable terminal design? A: It simplifies field wiring and provides easier maintenance access.
Q: Does the module support redundancy? A: Yes, redundancy is achieved by adding a second module to the IOTA base without external cabling.
Q: What is the difference between 8C and 8U versions? A: The 8C version includes conformal coating for added protection against moisture, dust, and chemicals, while the 8U version does not.
