Description
Overview
The Honeywell 8C-TDODA1 51307149-175 Digital Output Bussed module delivers 32 sourcing outputs at 24VDC, each supporting up to 100 mA. Honeywell designed this Series 8 I/O module for non-redundant applications, ensuring precise signal control and seamless integration with Experion PKS systems.
Technical Specifications
| Parameter |
Value |
| Model Number |
8C-TDODA1 51307149-175 |
| Manufacturer |
Honeywell |
| Module Type |
Digital Output Bussed |
| Output Channels |
32 sourcing outputs |
| Output Voltage / Current |
24 VDC / 100 mA per channel |
| Max Module Current |
3.2 A |
| Isolation |
1000 VAC RMS |
| Dimensions |
7 × 14 × 14.5 cm |
| Weight |
0.4 kg |
| HS Code |
8537101190 |
| Origin |
USA |
| System |
DCS / Experion PKS |
| Operating Temperature |
0°C to 60°C |
| Storage Temperature |
-40°C to 85°C |
| Communication Service |
Ethernet router |
| MOQ |
1 |
Design and Build
Honeywell engineered the 8C-TDODA1 51307149-175 with galvanic isolation of 1000 VAC RMS between system and field connections. Its compact dimensions and lightweight build simplify installation while ensuring durability in industrial environments.
Performance
The 8C-TDODA1 51307149-175 supports configurable safe-state behavior (FAILOPT), allowing channels to hold last values or shed to safe outputs during faults. Engineers can remove or insert the module while powered, enabling flexible maintenance without downtime.
Applications and Compatibility
The Honeywell 8C-TDODA1 51307149-175 integrates seamlessly with Series 8 I/O modules and Experion PKS systems. Industries rely on this module for process control, MES, and DCS applications. It manages actuators, valves, and pumps while supporting building automation tasks such as HVAC and energy management.
