Product Description
The Honeywell 621‑2201R is a high-reliability digital output module engineered for the TDC 3000 distributed control system. It offers six independently isolated 230 VAC output channels, ensuring safe operation when controlling high-voltage AC devices. Designed for continuous industrial use, this module delivers robust performance, electrical isolation, and easy status monitoring via integrated LEDs.
Key Features
-
Six fully isolated AC output channels
-
Supports standard 230 VAC loads
-
LED indicators for each output channel
-
Rugged industrial construction for high uptime
-
Compatible exclusively with Honeywell TDC 3000 systems
-
Reduces cross-channel interference and electrical faults
Technical Specifications
| Specification |
Details |
| Model Number |
621‑2201R |
| Output Channels |
6 isolated outputs |
| Output Voltage |
230 VAC |
| Isolation |
Full electrical isolation per channel |
| Maximum Load |
5–10 A per channel (depending on installation) |
| Status Indicators |
LED per output channel |
| Dimensions |
2 cm × 18 cm × 12.6 cm |
| Weight |
3.0 lbs |
Applications
The 621‑2201R module is commonly used for controlling motors, pumps, solenoid valves, alarms, and other 230 VAC equipment in critical industrial processes. Its isolated outputs make it ideal for environments where safety and system reliability are paramount.
Comparison with Similar Modules
-
Compared with standard TDC 3000 output modules, the 621‑2201R provides full electrical isolation for all channels, minimizing the risk of cross-channel faults.
-
Modules without isolation may be less expensive but require additional external safety relays.
FAQ
Q: Can this module switch inductive loads like motors?
A: Yes, the module is rated for AC inductive loads, but ensure the connected load does not exceed the maximum amperage per channel.
Q: Is this compatible with other Honeywell DCS systems?
A: The 621‑2201R is specifically designed for the TDC 3000 series and may not operate reliably in other Honeywell platforms.
