Description
Overview
The Honeywell 51454416-100 I/O Module is a rugged Ethernet interface device engineered for industrial automation networks. Honeywell designed this module to operate on 24VDC with 4.8W power consumption, ensuring reliable performance in harsh environments.
Technical Specifications
| Parameter |
Value |
| Model Number |
51454416-100 |
| Manufacturer |
Honeywell |
| Module Type |
I/O Module |
| Input Voltage |
24 VDC |
| Power Consumption |
4.8 W |
| Ethernet Ports |
2 × 10/100/1000BASE-T |
| Data Rate |
Up to 1000 Mbps |
| Isolation Protection |
1500 V AC |
| Surge Protection |
±2 kV |
| Connections Supported |
32 simultaneous Modbus TCP |
| MAC Address Table |
2048 entries |
| Dimensions |
7 × 14 × 14.5 cm |
| Weight |
0.4 kg |
| Operating Temperature |
-40°C to +70°C |
| Vibration Resistance |
5g @ 10–500 Hz |
| Humidity Range |
5–95% RH |
| HS Code |
8537101190 |
| Origin |
USA |
| System |
DCS / Experion PKS |
| Communication Service |
Ethernet router |
| MOQ |
1 |
Design and Build
Honeywell engineered the 51454416-100 with compact dimensions and strong environmental resistance. Its dual Ethernet ports support high-speed communication, while isolation and surge protection ensure network stability in demanding conditions.
Performance
The 51454416-100 delivers real-time control with latency under 5 μs and jitter below 500 ns. Its Modbus TCP support allows 32 simultaneous connections, while a MAC table of 2048 entries enhances scalability for complex automation systems.
Applications and Compatibility
The Honeywell 51454416-100 integrates seamlessly with Experion PKS and DCS systems. Industries deploy this module in oil and gas, manufacturing, and critical infrastructure networks. Its durability, high-speed communication, and compact design make it essential for automation environments requiring reliable Ethernet connectivity.
