Product Description
The Honeywell 51404126-150 is a high-performance 15-slot HPMM chassis engineered for Honeywell TPS, TDC 3000, and Experion PKS control systems. This rugged rack assembly provides secure mechanical support, robust backplane connectivity, and reliable power distribution for multiple control and I/O modules, ensuring long-term system stability and scalability in industrial automation environments.
Applications
Designed to house Honeywell controllers, communication cards, and I/O modules, this chassis enables modular system expansion while maintaining precise alignment and consistent electrical performance. Ideal for process control, plant monitoring, and distributed control system installations.
Key Features
-
Supports up to 15 HPMM modules for extensive system configurations
-
Ensures backplane connectivity for seamless module communication
-
Delivers stable power distribution and grounding across all installed modules
-
Modular design allows straightforward installation, maintenance, and upgrades
-
Passive airflow cooling with optional external fans for enhanced thermal management
-
Rugged construction for continuous operation in demanding industrial environments
Technical Specifications
| Specification |
Details |
| Slots |
15 HPMM module slots |
| Dimensions (L × W × H) |
29.5 × 21.5 × 4.5 in (750 × 545 × 115 mm) |
| Weight |
10 lbs |
| Cooling System |
Passive airflow; optional external fan installation |
| Power Supply |
Supports multiple supply configurations |
Comparison & Compatibility
Compared with 7-slot HPMM models like Honeywell 51404125-150, the 15-slot version offers greater module capacity for larger installations and higher system scalability. Compatible across Honeywell TPS, TDC 3000, and Experion PKS distributed control platforms.
FAQ
Q: Can this chassis be used independently of Honeywell control systems?
A: No, it requires installation within supported Honeywell TPS, TDC 3000, or Experion PKS architectures.
Q: Is external cooling necessary?
A: The chassis uses passive airflow cooling; external fans are optional for high-density or high-temperature installations.
Q: Are refurbished units reliable?
A: Refurbished units are tested to meet original specifications; warranty terms may vary by supplier.
