Product Description
The Honeywell 51402797-200 is a 16-channel analog input module engineered for Honeywell Distributed Control Systems, including Experion PKS and legacy TDC platforms. It acquires and converts analog signals from field instruments such as temperature, pressure, and flow sensors into digital data for precise monitoring and control. With Modbus RTU communication, dual Ethernet/RS-485 connectivity, and rugged aluminum construction, this module provides reliable performance in industrial environments. It is optimized for integration, high signal fidelity, and efficient cabinet space usage.
Technical Specifications
| Specification |
Details |
| Channels |
16 analog input channels |
| Signal Range |
0–10 VDC, 0–20 mA |
| Supported Signals |
4–20 mA current loop, 0–10 V voltage input |
| Sampling Rate |
~100 ms |
| Communication Protocol |
Modbus RTU |
| Connectivity |
1 × Ethernet, 1 × RS-485 |
| Power Consumption |
~5 W |
| Operating Temperature |
-20 °C to +60 °C (-4 °F to +140 °F) |
| Storage Temperature |
-40 °C to +85 °C (-40 °F to +185 °F) |
| Material / Protection |
Aluminum alloy housing, IP20 protection |
| Dimensions |
2 × 13.5 × 23.8 cm |
| Weight |
0.25 kg |
Key Features & Advantages
-
High-density design with 16 input channels reduces cabinet footprint
-
Supports both voltage (0–10 V) and current (4–20 mA) signals
-
Robust industrial-grade aluminum housing with IP20 protection
-
Modbus RTU communication and dual Ethernet/RS-485 interfaces for seamless integration
-
Diagnostics support for signal integrity and module health monitoring
Applications
The Honeywell 51402797-200 is suitable for:
-
Refining and petrochemical processes
-
Power generation monitoring and control
-
Chemical manufacturing instrumentation
-
Any system requiring high-accuracy analog signal acquisition
FAQ
Q: Can this module be used outside Honeywell systems?
A: It is primarily designed for Honeywell DCS platforms; limited functionality may be available in other systems with Modbus RTU.
Q: What is the maximum operating temperature?
A: The module operates up to +60 °C (+140 °F).
Q: How many input channels does it support?
A: 16 analog channels per module.
Q: What types of analog signals are supported?
A: Both 4–20 mA current loops and 0–10 V voltage signals.
