Description
Overview
The Honeywell 51401381-100 is a high-reliability 5-slot backpanel designed for the TDC 3000X Distributed Control System (DCS). It functions as a central mounting and connectivity platform, supporting critical modules such as application processors, history modules, universal stations, and gateway interfaces. Built for industrial environments, this interface card ensures stable communication and robust performance across a wide range of process automation applications.
Technical Specifications
| Feature |
Specification |
| Module Slots |
5 (compatible with processors, history modules, universal stations, gateways) |
| Dimensions |
12.7 × 10.2 × 2.5 cm |
| Weight |
0.72 kg |
| Operating Temperature |
-40 °C to +85 °C |
| Material |
Industrial-grade PCB with reinforced protective housing |
| Certifications |
CE, RoHS |
| Protection |
Vibration-resistant, EMI-shielded |
Key Features
-
Central hub for connecting multiple Honeywell DCS modules
-
Rugged construction with vibration and EMI resistance
-
Compact footprint suitable for tight control cabinet layouts
-
Wide operating temperature range for harsh industrial environments
-
Ensures reliable inter-module communication and signal integrity
Applications
-
Oil & Gas: Integration of control and gateway modules for pipeline and refinery operations
-
Chemical & Petrochemical: Supports complex control and monitoring modules
-
Power Generation: Mounting and communication for turbine or grid control modules
-
Pharmaceutical & Food Processing: Reliable operation in regulated production environments
-
Manufacturing: Backbone interface for automation modules in Honeywell DCS systems
