Description
Overview
The Honeywell 51400926-100 is a PDG (Processor Data Gateway) control board engineered for Honeywell TDC 2000 and TDC 3000 distributed control systems. It delivers dependable real-time processing and robust communication capabilities for industrial automation environments. Designed for legacy system support, this board combines compact design with high reliability for continuous plant operation.
Technical Specifications
| Feature |
Specification |
| Processor |
Freescale i.MX6 Solo ARM Cortex-A9 |
| Clock Speed |
72 MHz |
| RAM |
256 KB |
| Flash Memory |
1 MB |
| Dimensions |
12.0 × 8.0 × 5.0 cm |
| Weight |
3.28 lbs |
| Operating Environment |
Industrial Distributed Control Systems (DCS) |
Key Features
-
High-performance CPU optimized for industrial process control.
-
Compact and modular design enabling straightforward installation.
-
Reliable internal communication with Honeywell DCS systems.
-
Robust construction for harsh industrial environments.
-
Plug-and-play compatibility for TDC 2000/3000 series.
Applications
-
Oil & Gas: Process monitoring, safety systems, and plant automation.
-
Chemical & Petrochemical: Continuous plant operations and hazard management.
-
Power Generation: Turbine control, grid monitoring, and energy management.
-
Pharmaceutical & Food Processing: Precise control in regulated processes.
-
Manufacturing: Enhanced throughput and system reliability.
FAQ / Technical Notes
Q: Can this board be used in TDC 3000 legacy systems?
A: Yes, the 51400926-100 is fully compatible with both TDC 2000 and TDC 3000 series.
Q: What is the maximum operational environment?
A: Designed for standard industrial DCS environments; extreme temperature or vibration conditions should be evaluated.
Q: How does it compare to Honeywell 51400910-100 EMEM board?
A: The 51400926-100 PDG board focuses on processing and communication, whereas the 51400910-100 EMEM is memory expansion for historical and real-time data storage.
