Description
Product Overview
The Honeywell 51305482-102 Control Systems cable supports stable 100‑BASE‑T networking inside Experion PKS environments. The 2‑meter length offers flexible routing, while the compact 7×14×14.5 cm size and 0.4 kg weight simplify installation in dense DCS cabinets. Honeywell includes color‑coded boots in yellow and green to help technicians identify connections quickly during system setup.
Technical Specifications
| Parameter |
Specification |
| Model Number |
51305482-102 |
| Category |
Control Systems |
| Manufacturer |
Honeywell |
| System |
DCS / Experion PKS |
| Cable Length |
2 meters (6.5 ft) |
| Cable Type |
100‑BASE‑T |
| Conductor Size |
24 AWG |
| Impedance |
100Ω ±15% |
| Bandwidth |
100 MHz |
| Data Rate |
100 Mbps |
| DC Resistance |
≤9.38Ω per 100 m |
| Capacitance |
≤5.6 nF per 100 m |
| Operating Temperature |
0°C to +60°C |
| Storage Temperature |
−20°C to +75°C |
| Humidity Range |
5%–95% non‑condensing |
| Weight |
0.4 kg |
| Dimensions |
7 × 14 × 14.5 cm |
| HS Code |
8537101190 |
| Origin |
USA |
| Condition |
Brand New |
| MOQ |
1 |
Design & Performance
The Honeywell 51305482-102 uses 24 AWG conductors that support clean signal transmission across industrial networks. The 100Ω impedance and 100 MHz bandwidth maintain consistent performance during high‑demand communication tasks. The cable handles 100 Mbps data rates, enabling efficient communication between DCS components. Honeywell designs the 51305482-102 to maintain electrical stability through low resistance and controlled capacitance across long distances.
Environmental & Mechanical Characteristics
The Honeywell 51305482-102 operates reliably from 0°C to +60°C, supporting diverse industrial climates. The cable stores safely between −20°C and +75°C, which helps protect performance during transport. The 5%–95% humidity tolerance ensures dependable operation in facilities with fluctuating environmental conditions.
Installation & Integration
Technicians install the Honeywell 51305482-102 easily due to its flexible 2‑meter length and color‑coded boots. The compact dimensions support clean routing inside structured cabling systems. The cable integrates seamlessly with Experion PKS networks and other compatible Ethernet‑based control architectures.
Applications & Compatibility
The Honeywell 51305482-102 supports a wide range of industrial networking tasks, including:
-
DCS controller communication
-
Structured cabling inside Experion PKS systems
-
Industrial Ethernet connectivity
-
Control panel network expansion
-
High‑reliability automation networks
Its electrical stability and rugged construction make the 51305482-102 suitable for manufacturing, energy, and process automation environments.
