Product Description
The Honeywell 51305378-100 is a precision analog input termination module engineered for distributed control systems such as Honeywell TDC 3000 and Experion PKS. It provides stable termination and signal conditioning for industrial transmitters, ensuring accurate process data acquisition and seamless integration into DCS networks.
Technical Specifications
| Specification |
Details |
| Channels |
16 analog input channels (typical) |
| Supported Signals |
4–20 mA current loops, 0–10 V voltage signals |
| Accuracy |
High precision for process-level signals |
| Logic/Operating Voltage |
24 VDC |
| Operating Temperature |
-20°C to +70°C |
| Storage Temperature |
-40°C to +85°C |
| Dimensions |
135 × 25 × 200 mm |
| Weight |
0.55 lbs |
| Compatible Systems |
Honeywell TDC 3000, Experion PKS |
Key Features
-
Handles a wide range of process-level analog signals, including pressure, flow, and level transmitters.
-
Ensures reliable termination and accurate data transmission to the control processor.
-
Industrial-grade design suitable for harsh environmental conditions.
-
Optimized for Honeywell DCS platforms for smooth system integration.
-
Provides diagnostics support for signal integrity monitoring and fault detection.
Applications
-
Distributed control systems (DCS) in oil & gas, chemical, and power plants
-
High-density analog input environments requiring robust signal conditioning
-
Monitoring and control of field transmitters with 4–20 mA or 0–10 V outputs
FAQ
Q: Can this module support both current and voltage signals simultaneously?
A: Yes, the 51305378-100 can handle 4–20 mA current loops and 0–10 V voltage inputs concurrently.
Q: What is the maximum number of channels per module?
A: Typically, it supports 16 analog input channels per module.
Q: Is this module compatible with Experion PKS systems?
A: Yes, it is fully compatible with both TDC 3000 and Experion PKS platforms.
