Description
Overview
The Honeywell 51304920‑100 is a dedicated serial communication module engineered for the TDC 3000 Distributed Control System (DCS). It facilitates reliable data exchange between Honeywell controllers and external devices, ensuring precise process control and industrial automation performance. Compact and robust, this module is designed for continuous operation in challenging industrial environments.
Technical Specifications
| Specification |
Details |
| Manufacturer |
Honeywell |
| Part Number |
51304920‑100 |
| Module Type |
Serial Interface Module |
| System Compatibility |
Honeywell TDC 3000 DCS |
| Input Voltage |
24 VDC |
| Current Rating |
110 mA |
| Communication |
Serial interface (RS‑232 / RS‑485 configurable) |
| Dimensions |
30 × 20 × 25 cm (packaged) |
| Weight |
0.8 kg |
| Operating Temperature |
0 – 55 °C |
Key Features
-
Reliable Serial Communication: Stable data transfer for Honeywell TDC 3000 controllers.
-
Industrial-Grade Construction: Engineered for long-term operation in demanding environments.
-
Compact & Lightweight: Easy installation into standard control racks.
-
Flexible Protocol Support: Compatible with multiple serial protocols to integrate various devices.
-
Durable Design: Built to maintain consistent performance under continuous use.
Applications
-
Process Automation: Connects sensors, actuators, and subsystems to TDC 3000 systems.
-
Power Generation: Monitors and controls turbines, generators, and auxiliary equipment.
-
Manufacturing Systems: Integrates production line devices with central controllers.
-
Safety & Alarm Systems: Links interlocks, alarms, and emergency devices to the DCS.
FAQ
Q: Can this module be used with systems other than TDC 3000?
A: The 51304920‑100 is designed specifically for TDC 3000 systems and is not intended for standalone operation.
Q: What serial protocols are supported?
A: The module supports RS‑232 and RS‑485 communication, depending on configuration.
Q: What is the operating environment for this module?
A: Recommended installation is within a clean, controlled industrial environment to ensure stable communications.
