Product Description
The Honeywell 51304584-100 is a precision analog input termination module engineered for use with Honeywell TDC 3000 and Experion PKS distributed control systems. It provides reliable signal conditioning and termination for process-level transmitters, ensuring accurate data integration into the control system. Optimized for high-density analog input applications, this module supports robust operation in industrial environments.
Technical Specifications
| Specification |
Details |
| Channels |
16 analog input channels |
| Supported Signal Types |
4–20 mA current loops, 0–10 V voltage signals |
| Input Impedance |
250 Ω (for current signals), ≥10 kΩ (for voltage signals) |
| Accuracy |
±0.1% full scale typical |
| Operating Voltage |
24 VDC logic supply |
| Power Consumption |
5 W typical |
| Operating Temperature |
-20 °C to +70 °C |
| Storage Temperature |
-40 °C to +85 °C |
| Dimensions (L×W×H) |
200 × 135 × 25 mm |
| Weight |
0.44 lbs |
| System Compatibility |
Honeywell TDC 3000, Experion PKS |
| Diagnostics |
Signal integrity monitoring, channel fault detection |
Key Features
-
High-Density Analog Inputs: Supports up to 16 channels for efficient field data acquisition.
-
Accurate Signal Termination: Maintains precise measurement integrity for 4–20 mA and 0–10 V signals.
-
Industrial Reliability: Wide temperature range ensures stable operation under harsh conditions.
-
Seamless Integration: Fully compatible with Honeywell TDC 3000 and Experion PKS platforms.
-
Built-In Diagnostics: Facilitates early detection of signal faults and system issues.
Applications
-
Distributed control systems in oil & gas, chemical, and power plants
-
Monitoring and control of industrial transmitters producing standard analog signals
-
High-density analog input installations requiring reliable signal termination
FAQ / Comparison
Q: Can this module be used with low-level millivolt inputs?
A: This module is optimized for standard process-level signals; for low-level inputs like thermocouples or RTDs, use a Low-Level Analog Input (LLAI) module such as Honeywell 51304481 series.
Q: How does it differ from Honeywell 51304493-100?
A: The 51304584-100 is designed for high-density analog input applications and offers advanced diagnostics, whereas 51304493-100 focuses on general analog input termination with standard channel support.
