The Honeywell 51304537-100 is a high-performance ControlNet Interface I/O Board engineered for Honeywell TDC 3000 and Experion PKS systems. It enables fast and reliable communication between I/O modules and controllers, supporting critical industrial operations. Designed with a hot-swappable form factor and EMI-resistant construction, this board is ideal for environments requiring continuous uptime and robust signal integrity.
Functional Description
-
Facilitates high-speed data exchange between I/O modules and controllers using ControlNet protocol
-
Supports hot-swappable installation, allowing insertion or removal without powering down the rack
-
EMI-resistant multilayer PCB ensures stable operation in electrically noisy industrial environments
-
Provides seamless integration with Honeywell TDC 3000 and Experion PKS platforms
Key Features
-
High-Speed Communication: Rapid, reliable data transfer over ControlNet networks
-
Hot-Swap Capability: Minimizes downtime during maintenance or replacement
-
EMI-Resistant: Maintains signal integrity in challenging industrial environments
-
Industrial Durability: Suitable for petrochemical, power generation, metallurgy, and pulp & paper sectors
-
Flexible Integration: Compatible with TDC 3000 and Experion PKS systems for streamlined operations
Technical Specifications
| Specification |
Details |
| Model |
Honeywell 51304537-100 |
| Type |
ControlNet Interface I/O Board (CNI I/O) |
| Part Number |
51304537-100 Rev. C |
| System Compatibility |
Honeywell TDC 3000, Experion PKS |
| Interface Protocol |
ControlNet (industrial network standard) |
| Board Structure |
Industrial-grade multilayer PCB, EMI-resistant |
| Connector |
15-pin connector for Ethernet/ControlNet transceiver cable |
| Supported Cable Length |
Up to 50 meters |
| Power Supply |
On-board 5 VDC |
| Installation |
Rack-mounted, hot-swappable |
| Dimensions |
120 × 90 × 25 mm |
| Weight |
0.4 lbs |
Applications
-
High-speed communication between I/O modules and Honeywell controllers
-
Industrial distributed control systems (DCS)
-
Petrochemical, power generation, and other industrial process environments
-
Replacement or upgrade for existing Honeywell ControlNet interfaces
FAQ
Q: Can this board be installed without shutting down the rack?
A: Yes, the 51304537-100 is hot-swappable and can be replaced without interrupting system operation.
Q: What is the maximum cable length supported?
A: Supports ControlNet transceiver cables up to 50 meters.
Q: Is it compatible with both TDC 3000 and Experion PKS systems?
A: Yes, the board integrates seamlessly with both platforms.
