Description
Overview
The Honeywell 51304516-200 is a high-performance Transmitter Interface Processor (TIP), engineered for seamless integration with Honeywell’s distributed control systems, including TDC 3000 and Experion PKS. Designed for industrial-grade reliability, it supports up to 16 transmitter channels for precise, real-time signal acquisition and monitoring.
Technical Specifications
| Specification |
Details |
| Model |
51304516-200 |
| Module Type |
Transmitter Interface Processor (TIP / Smart TIP) |
| Channels |
16 transmitter inputs |
| Input Voltage |
10–30 VDC |
| Output Current |
0–20 mA / 4–20 mA |
| Operating Frequency |
8 kHz |
| Power Consumption |
≤1 W |
| Communication Protocols |
Modbus RTU, DeviceNet |
| Operating Temperature |
-40°C to +85°C |
| Environmental Protection |
IP67 |
| Dimensions |
80 × 100 × 25–30 mm |
| Weight |
0.7 kg |
| System Compatibility |
Honeywell TDC 3000, Experion PKS, Universal Control Network (UCN) |
Key Features
-
High-precision signal acquisition for process transmitters
-
Multi-channel support for up to 16 simultaneous inputs
-
Industrial durability: IP67 protection and wide temperature tolerance
-
Energy-efficient operation with ≤1 W power draw
-
Built-in diagnostics and LED fault indicators
-
Flexible integration via Modbus RTU and DeviceNet
Applications
-
Oil & Gas, Chemical, and Power Generation Process Monitoring
-
Real-time integration of pressure, temperature, flow, and level transmitters
-
Redundant and mission-critical automation environments
FAQ / Comparison
Q: Can this module operate standalone?
A: No, the 51304516-200 must be used within Honeywell DCS platforms.
Q: How does it differ from standard TIP modules?
A: The Smart TIP variant offers enhanced diagnostics, redundancy support, and multi-protocol communication compared to basic TIP modules.
