Description
Product Description
The Honeywell 51304493-100 is a high-reliability analog input termination module engineered for Honeywell TDC 3000 and Experion PKS distributed control systems. It is purpose-built for precise signal termination, conditioning, and routing of standard industrial process signals such as 4–20 mA current loops and 0–10 V voltage inputs.
Technical Specifications
-
Model / Part Number: 51304493-100
-
Module Type: Analog Input Termination Module
-
Supported Channels: 16 analog input channels
-
Signal Compatibility: 4–20 mA current loops, 0–10 V voltage signals
-
Input Accuracy: High precision for process-level signals
-
Operating Voltage: 24 VDC
-
Operating Temperature: -20°C to +70°C
-
Storage Temperature: -40°C to +85°C
-
Dimensions (L × W × H): 200 × 25 × 135 mm
-
Weight: 0.71 lbs
Key Features
-
Precise Signal Handling: Optimized for standard industrial transmitters including pressure, flow, and level sensors.
-
Stable Termination: Guarantees accurate and consistent data transmission from field devices to the control processor.
-
Industrial-Grade Durability: Operates reliably across wide temperature ranges for challenging environments.
-
Seamless DCS Integration: Fully compatible with Honeywell’s distributed control platforms.
-
Diagnostics and Monitoring: Supports fault detection and signal integrity checks.
Applications
-
Termination and signal conditioning of analog inputs in high-density DCS installations
-
Monitoring industrial transmitters providing 4–20 mA or 0–10 V outputs
-
Process control in oil & gas, chemical processing, and power generation industries
FAQ
Q: Can this module handle both voltage and current input signals?
A: Yes, the module supports 4–20 mA current loops and 0–10 V voltage signals.
Q: Is it compatible with Honeywell Experion PKS?
A: Yes, it is fully compatible with both TDC 3000 and Experion PKS systems.
Q: What is the maximum number of channels supported?
A: Typically 16 analog input channels per module.
Q: Are there similar models with expanded signal support?
A: The Honeywell 51304489-100 supports similar analog inputs with additional signal conditioning features for high-level analog signals.
