Product Description
The Honeywell 51304489-100 is a high-level analog input (HLAI) termination module designed for precise integration into Honeywell TDC 3000 and Experion PKS distributed control systems. It provides robust signal termination, conditioning, and routing for standard industrial analog inputs. This module ensures reliable data acquisition from process transmitters and sensors in demanding industrial environments.
Technical Specifications
-
Model / Part Number: 51304489-100
-
Module Type: High-Level Analog Input (HLAI) Termination Module
-
Input Channels: 16 analog input channels
-
Signal Compatibility:
-
4–20 mA current loops (through 250 Ω load)
-
0–5 V, 1–5 V, 0–4 V, and 0–10 V voltage inputs
-
Input Scan Rate: 4 samples per second per channel
-
Accuracy: High precision for process-level signals
-
Operating Voltage: 24 VDC logic level
-
Operating Temperature: -20 °C to +70 °C
-
Storage Temperature: -40 °C to +85 °C
-
Dimensions: 135 × 25 × 200 mm
-
Weight: 1.61 lbs
Key Features
-
Handles standard industrial process-level analog signals with high fidelity
-
Durable for extreme temperature ranges and industrial environments
-
Supports high-density input applications with 16 channels
-
Provides integrated diagnostics for signal integrity monitoring
-
Seamless integration into Honeywell distributed control systems
Applications
-
Continuous monitoring of pressure, flow, temperature, and level transmitters
-
Integration of 4–20 mA and 0–10 V signals into DCS for process control
-
High-density analog input environments requiring reliable termination
FAQ
Q: Can this module accept multiple voltage ranges?
A: Yes, it supports 0–5 V, 1–5 V, 0–4 V, and standard 4–20 mA signals.
Q: What is the input scan rate for real-time monitoring?
A: Each channel samples at 4 samples per second, suitable for typical process control applications.
Q: Is it compatible with other Honeywell analog modules?
A: It integrates seamlessly with Honeywell TDC 3000 and Experion PKS systems and complements other HLAI and LLAI modules.
