Description
Overview
The Honeywell 51196814‑200 is a precision differential pressure transmitter engineered for industrial monitoring and process control applications. It accurately measures pressure differences between two points, making it ideal for monitoring air and other non-corrosive gases. Its compact design, high accuracy, and robust performance allow seamless integration into DCS, PLC, or HVAC systems, supporting reliable operation in diverse industrial environments.
Technical Specifications
| Specification |
Details |
| Manufacturer |
Honeywell |
| Part Number |
51196814‑200 |
| Product Type |
Differential Pressure Transmitter |
| Measurement Range |
Differential pressure for gases including air |
| Accuracy |
High accuracy for critical process control |
| Output Signal |
4–20 mA analog signal |
| Power Supply |
24 VDC typical |
| Communication |
Compatible with DCS and PLC systems |
| Dimensions |
216 × 160 × 30 mm (8.5 × 6.3 × 1.2 in) |
| Weight |
0.5 kg |
| Operating Temperature |
Standard industrial range |
| Certifications |
CE compliant |
Key Features
-
High-Precision Measurement: Provides accurate differential pressure readings for process optimization.
-
Compact and Lightweight: Easy to install in panels, ducts, or field enclosures.
-
Versatile Applications: Suitable for air and other non-corrosive gases.
-
Reliable Operation: Designed for continuous performance in industrial settings.
-
Seamless Integration: Fully compatible with Honeywell DCS, PLC, and other control systems.
Applications
-
Process Automation: Monitoring pressure differences in pipelines, vessels, and ducts.
-
HVAC Systems: Ensuring proper airflow, filter monitoring, and system efficiency.
-
Industrial Gas Monitoring: Detecting pressure variations in non-corrosive gases.
-
Power Plants & Manufacturing: Supporting safe, efficient, and stable operations.
FAQ
Q: What type of gases can the 51196814‑200 measure?
A: It is designed for air and other non-corrosive gases in industrial environments.
Q: What output signal does it provide?
A: The transmitter provides a standard 4–20 mA analog output compatible with PLC and DCS systems.
Q: Can it be integrated with Honeywell DCS systems?
A: Yes, it is fully compatible with Honeywell DCS and other automation controllers.
Q: What is the typical operating environment?
A: Suitable for standard industrial temperatures, panel, or duct installation.
