Description
Product Overview
The Honeywell 51155506-105 Power Supply Module delivers reliable high‑power load control inside Experion PKS and other DCS platforms. The compact 7×14×14.5 cm structure and 0.4 kg weight support efficient installation in dense automation cabinets. Honeywell designs the 51155506-105 to manage motors, solenoids, and contactors through robust relay outputs.
Technical Specifications
| Parameter |
Specification |
| Model Number |
51155506-105 |
| Category |
Power Supply / Relay Module |
| Manufacturer |
Honeywell |
| System |
DCS / Experion PKS |
| Input Voltage |
120/240 V AC |
| Output Current |
10 A Continuous |
| Relay Contacts |
Form A (NO) / Form B (NC), SPDT |
| Channel Rating |
5 A per Channel |
| Voltage Rating |
300 V AC/DC |
| Isolation |
1500 V AC Channel‑to‑Channel |
| Switching Life |
Up to 100,000 Operations |
| Included Cable |
5‑meter DO (Source) Relay Cable |
| Weight |
0.4 kg |
| Dimensions |
7 × 14 × 14.5 cm |
| Humidity Range |
5%–95% Non‑condensing |
| HS Code |
8537101190 |
| Origin |
USA |
| Condition |
Brand New |
| MOQ |
1 |
Design & Performance
The Honeywell 51155506-105 uses SPDT relay contacts that support both normally open and normally closed configurations. The module handles 10 A continuous load, enabling stable operation of high‑power devices. The 300 V AC/DC rating and 1500 V isolation strengthen electrical safety and noise immunity. Honeywell integrates an LED indicator that helps technicians monitor relay status during operation.
Electrical & Environmental Characteristics
The Honeywell 51155506-105 maintains consistent performance across a 5%–95% humidity range. The module supports long‑term reliability through a 100,000‑cycle switching lifespan. The compact footprint improves panel layout flexibility, while the included 5‑meter relay cable simplifies wiring during installation.
Installation & Integration
Technicians integrate the Honeywell 51155506-105 quickly due to its clear relay layout and universal 120/240 V input support. The module fits seamlessly into 5115 series PLC systems and broader Experion PKS architectures. The relay cable assembly enhances connectivity and reduces installation time in high‑density control panels.
Applications & Compatibility
The Honeywell 51155506-105 supports a wide range of industrial and commercial applications, including:
-
Industrial automation and machinery control
-
HVAC equipment and building systems
-
Lighting control networks
-
Security and access control systems
-
High‑power device switching in DCS environments
Its strong electrical ratings and durable relay design make the 51155506-105 suitable for demanding process environments.
