Description
Overview
The Honeywell 51155506-100 Relay Module provides six isolated analog output channels designed for integration with the C200 controller family. Engineers rely on its ±0.1% accuracy, 12-bit resolution, and compact 0.4 kg design to ensure reliable performance in process control, building automation, and HVAC systems.
Technical Specifications
| Parameter |
Details |
| Model Number |
51155506-100 |
| Manufacturer |
Honeywell |
| Module Type |
Relay Module |
| Dimensions |
7 × 14 × 14.5 cm |
| Weight |
0.4 kg |
| HS Code |
8537101190 |
| Channels |
6 isolated analog outputs |
| Output Range |
0–10 V, 20 mA per channel |
| Accuracy |
±0.1% full scale |
| Resolution |
12-bit |
| Power Supply |
24 VDC, 100 mA consumption |
| Update Time |
2 ms |
| Isolation |
Individual channel isolation |
| Cable Assembly |
0.5 m relay cable included |
| System Compatibility |
Experion PKS, DCS, C200 family |
| Condition |
Brand New |
| Origin |
USA |
| MOQ |
1 |
| Communication Service |
Ethernet router |
| Discontinued On |
Active |
Functional Highlights
Honeywell designed the 51155506-100 to deliver precise voltage outputs with fast 2 ms update times, ensuring responsiveness in real-time control applications. Each channel is individually isolated, preventing cross-talk and maintaining signal integrity in noisy environments.
The 51155506-100 operates on a 24 VDC supply with low power consumption of 100 mA. Its included 0.5-meter relay cable assembly simplifies connectivity, reducing installation time and ensuring durability in critical applications.
Applications and Compatibility
The Honeywell 51155506-100 suits industries requiring robust analog output modules, including manufacturing automation, building management, and energy systems. Engineers deploy this module to enhance system stability, improve efficiency, and ensure seamless integration with Honeywell’s Experion PKS and C200 controller platforms. Its precision, isolation, and reliability make it a trusted solution for modern industrial automation.
