Description
Product Description
The Honeywell 2MLQ‑RY2A is a compact 2-channel relay output module engineered for the MasterLogic‑200 PLC platform. It delivers reliable switching for external devices including solenoids, contactors, and indicator lamps, making it suitable for discrete automation tasks in industrial environments.
Key Technical Specifications
| Specification |
Details |
| Model |
2MLQ‑RY2A |
| Type |
Relay Output Module (2 Channels) |
| Output Configuration |
NO/NC Relay Contacts |
| Voltage Range |
24 VDC or 120 VAC (depending on load) |
| Maximum Load Current |
2 A per channel |
| Channels |
2 Relay Outputs |
| Dimensions (L × W × H) |
172 × 120 × 114 mm |
| Weight |
0.45 kg |
| Operating Temperature |
-20°C to +60°C |
| Storage Temperature |
-25°C to +70°C |
| Vibration Tolerance |
Occasional Industrial Vibration |
| Atmosphere |
Non-corrosive, minimal dust environment |
Features and Advantages
-
Compact Footprint: Fits efficiently into MasterLogic‑200 PLC racks without consuming excess space.
-
Flexible Output Control: Supports normally open and normally closed relay contact configurations.
-
Industrial Reliability: Certified to CE, UL, CSA, and TUV standards for safe and consistent operation.
-
Seamless Integration: Designed to work directly with Honeywell MasterLogic‑200 systems.
-
Stable Switching: Provides consistent performance under standard industrial load conditions.
Applications
Ideal for machine automation, discrete device control, small-scale industrial processes, and any application requiring precise relay actuation in a PLC-controlled environment.
FAQ
Q: Can this module control AC loads?
A: Yes, it can switch AC loads up to 120 VAC, with a maximum current of 2 A per channel.
Q: Is the relay contact configurable?
A: The module supports both Normally Open (NO) and Normally Closed (NC) configurations.
Q: How does it differ from the 2MLL‑C42A module?
A: Unlike the 42-channel 2MLL‑C42A, the 2MLQ‑RY2A is a compact 2-channel relay module designed for applications needing only a few discrete outputs.
