Description
Product Description
The Honeywell 2MLF‑DC8A is an 8-channel analog current output module engineered for the MasterLogic‑200 PLC platform. Designed for precision control of actuators, valves, and motors, this module provides reliable and configurable 0–20 mA or 4–20 mA output per channel, meeting demanding industrial automation requirements.
Technical Specifications
| Specification |
Details |
| Channels |
8 Analog Current Outputs |
| Output Type |
Configurable 0–20 mA or 4–20 mA DC |
| Maximum Load Resistance |
≤ 550 Ω |
| Supply Voltage |
24 V DC |
| Dimensions |
172 × 120 × 114 mm |
| Weight |
0.77 lbs |
| Certifications |
CE, UL508, CSA, TUV |
| Operating Temperature |
–10 °C to 55 °C |
Key Features
-
Configurable current outputs for precise control of industrial devices
-
Compact design minimizes cabinet space and simplifies installation
-
Fully certified for CE, UL, CSA, and TUV compliance
-
Seamless integration with Honeywell MasterLogic‑200 PLC systems
-
Modular design enables easy replacement and maintenance
Applications
Commonly deployed in machine automation, process control, petrochemical plants, and power generation facilities, the 2MLF‑DC8A ensures accurate analog control and reliable operation under industrial conditions.
FAQ
Q: Can each channel be configured independently?
A: Yes, each of the 8 output channels can be individually set to 0–20 mA or 4–20 mA via software parameters.
Q: What is the maximum load resistance for stable operation?
A: Up to 550 Ω per channel.
Q: Are there similar modules for larger I/O needs?
A: Honeywell offers multi-channel D/A modules in the MasterLogic series with higher channel counts or combined analog/digital outputs for complex automation setups.
