The Honeywell 10024/1/1 Enhanced Communication Module is a specialized rack-mounted interface unit engineered for high-reliability communication management within Honeywell industrial automation architectures. This module facilitates stable, deterministic data exchange between controller backplane systems and connected subsystems, ensuring consistent performance in demanding process automation environments such as power plants, oil refineries, and large-scale manufacturing facilities. By providing robust signal buffering and protocol mediation, the 10024/1/1 minimizes communication faults and maintains signal integrity even in electrically noisy industrial settings.
Features
- Designed for seamless integration into standard Honeywell rack-based control architectures.
- Provides deterministic communication behavior for critical control loops.
- Features internal AC-to-DC power conversion to support stable 5 VDC logic rails.
- Engineered for high electrical isolation and signal stability.
- Supports continuous operation in industrial environments with high uptime requirements.
Applications
This module is primarily utilized in critical control applications where system availability and data synchronization are paramount. Typical deployments include distributed control systems (DCS) in the energy sector, petrochemical processing, and complex manufacturing automation where reliable communication between processors and field-level nodes is required.
Technical Specifications
| Model |
10024/1/1 |
| Brand |
Honeywell |
| Product Type |
Enhanced Communication Module |
| Input Voltage |
220 to 240 VAC |
| Frequency |
50 to 60 Hz |
| Internal Logic Supply |
5 VDC |
| Current Consumption |
850 mA |
| Operating Temperature |
0 to 60 deg C |
Installation Guidelines
- Ensure the control cabinet power is disconnected before installing or removing the module from the rack.
- Verify that the rack slot is clean and free of debris to ensure proper backplane connector alignment.
- Handle the module using ESD-safe practices to prevent damage to internal sensitive electronic components.
- Ensure the module is fully seated and secured in the chassis to maintain reliable backplane contact.
- Route signal cables away from high-voltage power lines or high-EMI sources to maintain signal integrity.
- Verify that the cabinet cooling system is operational, as the module is rated for an ambient temperature range of 0 to 60 deg C.
FAQ
What is the primary function of the 10024/1/1 module?
The 10024/1/1 acts as an enhanced communication interface that handles data exchange, protocol mediation, and signal buffering between the controller backplane and external subsystems.
Does this module require an external power supply?
The module accepts a 220 to 240 VAC input, which it converts internally to the required 5 VDC logic supply for operation within the rack.
