Description
The Honeywell 10014/I/F is a high-integrity digital output module engineered for safety-critical applications. Designed specifically for Safety Instrumented Systems (SIS), this module provides 8 isolated 24 VDC solid-state channels, ensuring reliable de-energization to a safe state when a fault is detected. Its robust architecture is suitable for demanding industrial environments including chemical processing, power generation, and oil refineries where deterministic equipment shutdown is essential.
Features
- 8 independent, isolated sourcing digital output channels.
- Fail-safe solid-state design ensures outputs transition to a de-energized state during power loss or internal diagnostic failure.
- Optimized for direct control of field actuators, such as solenoids, relays, and emergency shutdown valves.
- Rack-mount configuration for efficient integration into Honeywell safety backplane systems.
- High-speed switching performance with no mechanical wear components.
Applications
This module is primarily utilized in safety-critical loops where high availability and system integrity are required. It serves as a key component in emergency shutdown systems (ESD), fire and gas monitoring, and burner management systems where maintaining a safe state is the primary operational requirement.
Technical Specifications
| Model |
10014/I/F |
| Output Channels |
8 Isolated |
| Output Type |
Solid State Sourcing |
| Rated Voltage |
24 VDC |
| Output Current |
550 mA per channel |
| Max Lamp Load |
120 mA (approx. 2.9 W) |
| Max Load Capacitance |
1 uF |
| Voltage Drop |
< 2.0 V at 500 mA |
| Off-State Leakage |
< 0.1 mA |
| Power Consumption |
3 W to 5 W (load dependent) |
| Operating Temperature |
0 to 60 deg C |
Installation Guidelines
- Ensure the system power is completely disconnected before inserting or removing the module from the rack.
- Verify that all field wiring is properly shielded and routed away from high-voltage AC lines to minimize electromagnetic interference.
- Maintain proper ventilation within the cabinet to ensure the module operates within its specified temperature range.
- Confirm proper grounding of the rack backplane to prevent noise-related faults in safety-critical circuits.
- Handle with standard ESD precautions to prevent damage to sensitive internal electronic components.
FAQ
What is the primary function of the 10014/I/F module?
The 10014/I/F is designed for safety-instrumented systems to provide reliable, fail-safe digital outputs that de-energize to a safe state upon internal fault detection.
Is this module compatible with standard Honeywell safety racks?
Yes, this module is designed for standard rack-mount installation within compatible Honeywell safety system backplanes.
