The Honeywell 05704-A-0121 05704-A-0131 is a four-channel relay interface card engineered for industrial control and automation systems. It provides reliable switching outputs for integrating sensors, alarms, or external devices, delivering fast response and dependable performance in process control, safety monitoring, and general automation applications. Its compact footprint and durable construction allow easy installation in control panels or equipment racks.
Technical Specifications
| Specification |
Details |
| Manufacturer |
Honeywell |
| Part Number |
05704-A-0121 05704-A-0131 |
| Module Type |
Quad Relay Interface Card |
| Relay Outputs |
4 independent channels (SPCO relays) |
| Operating Voltage |
220 V AC |
| Current Rating |
10 A per relay |
| Relay Type |
Bipolar |
| Switching Speed |
<1 ms response time |
| Power Consumption |
Typical: 3.5 W, Maximum: 6.5 W |
| Operating Temperature |
-20 °C to +60 °C |
| Dimensions |
12.2 × 5.2 × 13.2 cm |
| Weight |
0.5 kg |
Key Features
-
Four Independent Relays: Flexible control of multiple devices or circuits.
-
High-Speed Switching: Sub-1 ms response ensures real-time performance.
-
Compact Footprint: Designed for space-efficient installation in panels or racks.
-
Durable Construction: Built for industrial environments with wide temperature tolerance.
-
Versatile Connectivity: Interfaces with sensors, alarms, or external devices via RS‑485.
-
Reliable Performance: Rated for continuous operation in industrial automation and safety systems.
Applications
-
Gas Detection Systems: Relay outputs for alarms, fans, or emergency shutdowns.
-
Process Automation: Control of pumps, valves, actuators, or other devices.
-
Safety Monitoring: Emergency stop circuits, interlocks, and safety signaling.
-
Industrial Control Panels: General-purpose relay interfacing for machinery and automation equipment.
FAQ
Q: How many relay outputs does the 05704‑A‑0121 provide?
A: The module includes four independent SPCO relay outputs for versatile control.
Q: What is the switching speed of the relays?
A: The relays switch in under 1 millisecond, enabling fast, real-time response.
Q: Can this module handle high current devices?
A: Yes, each relay is rated for 10 A at 220 V AC.
Q: Is the 05704‑A‑0121 suitable for compact panel installations?
A: Absolutely, its small footprint and rugged design allow integration in space-constrained control panels.
