Description

Honeywell CC-TAIX11 HART Analog Output Module

Configured for analog signal output execution in Honeywell Experion PKS C300 architecture, the Honeywell CC-TAIX11, also cataloged as the CC-TAIX11 HART Analog Output Module, provides direct electrical interface termination for field-side current loop output channels within distributed control I/O subsystems.

The module functions as a HART-enabled analog output interface supporting 4-20 mA loop signaling with digital overlay communication. Electrical drive capacity is specified at 0.195 A with 24 VDC nominal supply. Field wiring is routed through a fixed 12 inch rear termination arrangement for cabinet integration.

Hardware Specifications

Parameter	Specification
Model	CC-TAIX11
Brand	Honeywell
Origin	USA
Dimensions	12 inch termination assembly (R-12 inch)
Operating Temp	Not specified
Power Consumption	24 VDC, 0.195 A
Output Type	Analog Output, HART enabled (4-20 mA loop)
System Compatibility	Experion PKS / C300 I/O subsystem

Process Control Loop Electrical Characteristics (HART Analog Output Layer)

Within Honeywell Experion C300 architectures, the module participates in 4-20 mA HART loop protocol execution, where analog current output is superimposed with FSK digital communication signals. Channel-level signal integrity depends on loop impedance matching and correct grounding of shielded field cabling. The output stage is designed for controlled current sourcing behavior into standard process instrumentation loads, with HART carrier modulation preserved across the loop without separation of physical wiring layers.

Frequently Asked Questions (FAQ)

Q: Does the CC-TAIX11 support hot-swap replacement in a live I/O rack?
A: Hot-swap capability depends on C300 chassis configuration. Electrical loop must be placed in safe state or isolated prior to module extraction to prevent current interruption transients.

Q: What is the backplane load behavior of the CC-TAIX11?
A: The module draws power from the C300 backplane at 24 VDC nominal input level. Exact backplane current distribution is managed by chassis power segmentation and is not independently configurable at module level.

Q: Is HART communication maintained during analog output operation?
A: Yes. HART digital signal is multiplexed over the same 4-20 mA loop using FSK modulation without requiring additional physical conductors.

Field Installation Guidelines

• Ensure loop wiring is isolated from high-voltage switching conductors to minimize induced noise on 4-20 mA current paths
• Maintain shield termination at a single grounded point to avoid ground loop formation
• Verify loop resistance is within transmitter and field device operational limits prior to energization
• Insert module only into compatible Honeywell C300 I/O termination base with power removed
• Confirm polarity alignment for current loop terminals before commissioning

Specifications

• Brand: Honeywell

Advantages

• High reliability in industrial environments
• Supports continuous operation
• Compatible with major PLC/DCS systems
