The General Electric IC660EBA101 is a high-performance Electronics Assembly designed for the Genius I/O block system. This module provides reliable input signal processing and communication within industrial control networks, utilizing the established Genius protocol for seamless integration into GE automation architectures.
Features
- Designed for the Genius I/O Block series.
- Features 6 discrete inputs organized into 3 isolated groups.
- Integrated LED diagnostics including 1 unit status LED and 1 input status LED.
- Robust isolation: 1500 V rms group-to-group and block-to-block isolation.
- Configurable input update frequencies of 400, 800, or 1600 ms.
- Supports wide power supply ranges for both AC and DC applications.
Technical Specifications
| Model |
IC660EBA101 |
| Manufacturer |
General Electric |
| Input Configuration |
6 inputs in 3 isolated groups |
| AC Supply Voltage |
93-132 VAC (47-63 Hz) |
| DC Supply Voltage |
105-145 VDC (10% ripple) |
| Isolation |
1500 V rms |
| Heat Dissipation |
7 Watts |
| Operating Temperature |
0 to 60 degC |
| Storage Temperature |
-40 to 100 degC |
Installation Guidelines
- Ensure the system power is disconnected before installing or removing the electronics assembly from the I/O block base.
- Verify that the supply voltage matches the specified range (93-132 VAC or 105-145 VDC) to prevent damage.
- Maintain proper ventilation within the enclosure to accommodate the 7W heat dissipation.
- Follow standard ESD (Electrostatic Discharge) handling procedures when touching internal components.
- Ensure all wiring is securely terminated and that isolation barriers are maintained between input groups.
FAQ
What is the primary function of the IC660EBA101?
The IC660EBA101 is an electronics assembly for a Genius I/O block, used to interface field input signals with a Genius-based control network.
What is the isolation rating for this module?
The module provides 1500 V rms isolation between groups and block-to-block, ensuring signal integrity and protection against electrical noise.
Can this module operate on DC power?
Yes, the module is designed to operate on a DC supply voltage range of 105-145 VDC with up to 10% ripple.
