Description
Product Overview
The General Electric IS200WETBH1B belongs to the Mark VI Speedtronic series and functions as an elevator control board. Engineers use this module to manage turbine control signals, ensuring reliable monitoring of flame detection, vibration, shaft voltage, and synchronization. Its compact design, measuring 12.8 × 8.2 × 6 cm and weighing 0.38 kg, supports efficient installation in demanding DCS environments.
Technical Specifications
| Parameter |
Specification |
| Model Number |
IS200WETBH1B |
| Module Type |
Elevator Control Board |
| Manufacturer |
GE |
| Series |
EX2100 / Speedtronic Mark VI |
| System |
DCS |
| Dimensions |
12.8 × 8.2 × 6 cm |
| Weight |
0.38 kg |
| HS Code |
8537101190 |
| Condition |
Brand New |
| Origin |
USA |
| Lead Time |
In Stock |
| MOQ |
1 |
| Status |
Active |
| Communication Service |
Ethernet router |
| Connectors |
Over 65 connectors, female jacks (4–12 positions) |
| Male Connectors |
10-pin (P1), 6-pin (P2), 4-pin (P3) |
| Relays |
30+ relays in two types |
| Fuses |
10 integrated fuses |
| Heat Sinks |
7 |
| Voltage Regulators |
9 |
| Transformer |
1 |
| Inductors |
Coil inductors included |
| Test Points |
Multiple TP locations |
| Integrated Circuits |
50+ ICs |
| Capacitors |
High-voltage electrolytic capacitors |
| Resistors |
Metal film resistors |
| Additional Components |
Varistors, jumpers, single switch |
Functional Highlights
The GE IS200WETBH1B integrates more than 65 connectors, three vertical male connectors, and multiple female jacks to ensure versatile wiring options. Engineers rely on its transformer, relays, and fuses to manage turbine control safely. Seven heat sinks and nine voltage regulators stabilize performance, while over fifty integrated circuits enhance processing capability.
A copper strip along the board edges and factory-drilled mounting points simplify installation. The IS200WETBH1B remains a highly component-dense solution, offering robust control and monitoring functions for turbine systems.
Applications and Compatibility
The General Electric IS200WETBH1B supports steam and gas turbine control systems within the Speedtronic Mark VI series. Operators deploy this elevator control board in industrial power generation environments requiring precise synchronization and reliable monitoring.
Compatibility with EX2100 excitation systems ensures smooth integration, while its rugged design reduces downtime and maintenance costs. The IS200WETBH1B continues to serve as a trusted solution for engineers maintaining GE’s legacy turbine control systems.
