Description
Overview
The IC670CHS002 terminal block from General Electric’s FANUC Field Control family is designed as a durable wiring base for distributed I/O installations. It provides a stable mechanical and electrical interface for Field Control modules, ensuring reliable signal routing and uninterrupted communication within DCS and industrial automation architectures.
Key Features
-
Compatible with GE FANUC Field Control I/O modules
-
Three isolated terminal commons (A, B, E) for structured power and signal grouping
-
Supports module replacement without disturbing field wiring
-
Rugged screw‑clamp terminals designed for vibration‑prone environments
-
Optimized for high‑speed backplane communication up to 1 Mbps
-
Suitable for Genius Bus and Ethernet‑based control networks
-
Compact footprint for dense panel layouts
Technical Specifications
| Parameter |
Specification |
| Model |
IC670CHS002 |
| Product Type |
Terminal Block |
| Brand |
General Electric |
| Product Range |
FANUC Field Control |
| Condition |
New |
| System Compatibility |
DCS / Field Control |
| Communication Support |
Ethernet‑based routing (system dependent) |
| Terminal Groups |
A, B, E (isolated commons) |
| Terminals |
1–16 for I/O wiring |
| Weight |
0.74 kg |
| Dimensions |
16.5 × 9 × 10 cm |
| HS Code |
8537101190 |
| Minimum Order |
1 unit |
| Origin |
USA |
| Availability |
In stock |
| Lifecycle Status |
Active |
Functional Description
The IC670CHS002 serves as the mechanical and electrical foundation for GE Field Control modules. Its isolated A/B/E terminal groups allow engineers to separate power, signal, and specialty wiring to reduce noise and improve diagnostic clarity. The E‑group’s five dedicated common terminals are particularly useful for applications requiring isolated reference points or specialized grounding schemes.
The block’s design ensures that modules can be swapped without disconnecting field wiring, reducing downtime during maintenance. Its screw‑mount structure provides strong resistance to vibration, making it suitable for heavy‑duty industrial environments.
Application Scenarios
-
Distributed I/O in DCS and PLC systems
-
High‑noise industrial environments requiring clean signal routing
-
Modular control panels with frequent module replacement
-
Process automation, material handling, and manufacturing lines
FAQ
Q: Can the IC670CHS002 support two modules on one block? A: Yes. The block accommodates two modules while maintaining independent wiring integrity.
Q: Are the terminal commons electrically isolated? A: The A, B, and E groups are isolated to support flexible wiring schemes and reduce interference.
Q: Is this block compatible with Genius Bus networks? A: It supports Field Control modules that interface with Genius Bus and Ethernet‑based systems.
