The General Electric DS200TBQDG1AFF belongs to the Mark V Speedtronic series and functions as an RST extension terminal board. Engineers use this PCB to extend turbine control connections, ensuring reliable integration with DCS systems. Its compact design, measuring 28.6 × 21.3 × 4 cm and weighing 0.38 kg, supports efficient installation in demanding industrial environments.
Technical Specifications
| Parameter |
Specification |
| Model Number |
DS200TBQDG1AFF |
| Module Type |
RST Extension Terminal Board |
| Manufacturer |
GE |
| Series |
Multilin / Speedtronic Mark V |
| System |
DCS |
| Dimensions |
28.6 × 21.3 × 4 cm |
| Weight |
0.38 kg |
| HS Code |
8537101190 |
| Condition |
Brand New |
| Origin |
USA |
| Lead Time |
In Stock |
| MOQ |
1 |
| Status |
Active |
| Communication Service |
Ethernet router |
| Processor |
80196 microprocessor |
| Memory |
PROM modules (erasable, reprogrammable) |
| Connectors |
Two 50-pin connectors (JCC, JDD) |
| Indicators |
One LED for status |
Functional Highlights
The GE DS200TBQDG1AFF integrates an 80196 microprocessor and multiple PROM modules to manage turbine control signals. Engineers rely on its two 50-pin connectors for seamless interfacing with other system components. A side-view LED provides quick operational feedback, while PROM modules allow firmware updates for enhanced functionality.
Its design emphasizes accessibility and reliability, ensuring compatibility with legacy Mark V systems. The DS200TBQDG1AFF continues to support turbine control applications by offering advanced signal management and diagnostic capabilities.
Applications and Compatibility
The General Electric DS200TBQDG1AFF supports wind, steam, and gas turbine control systems within the Speedtronic Mark V series. Operators deploy this extension terminal board in industrial power generation environments requiring stable connectivity and reliable diagnostics.
Compatibility with other Mark V modules ensures smooth integration, while its durable construction reduces downtime and maintenance costs. The DS200TBQDG1AFF remains a trusted solution for maintaining and servicing GE’s legacy turbine control systems.
