Description
The General Electric DS200DMCBG1A is a specialized processor board designed for use within the Mark V control series. This DOS DUP (Digital Output Processor) board serves as a critical component in turbine and gas control systems, providing the necessary computational logic and I/O management required for complex industrial automation environments.
Features
- Integrated DOS DUP processor architecture for reliable control execution.
- Equipped with 128 MB of on-board SDRAM for system memory operations.
- Includes 256 MB of Flash program memory for stable firmware and configuration storage.
- Features 16-bit resolution for high-precision analog scanning capabilities.
- Engineered for robust performance in demanding industrial thermal conditions.
Applications
This processor board is primarily utilized in General Electric Mark V turbine control systems. It is essential for managing multi-input/output data streams in gas and steam turbine management, ensuring precise regulation of control loops and system diagnostics.
Technical Specifications
| Model |
DS200DMCBG1A |
| System Memory |
128 MB SDRAM |
| Program Memory |
256 MB Flash |
| Analog Scan Resolution |
16-bit |
| Operating Temperature |
-40 degC to +70 degC |
| Storage Temperature |
-40 degC to +85 degC |
| Manufacturer |
General Electric |
Installation Guidelines
- Ensure the control system is powered down completely before attempting to install or remove the board from the rack.
- Handle the module using proper electrostatic discharge (ESD) protection measures to prevent damage to integrated circuits.
- Verify that the board is correctly seated in the designated slot to ensure proper backplane connection.
- Check all cable connections for secure contact to prevent signal degradation or intermittent communication errors.
- Maintain adequate ventilation within the cabinet to stay within the specified operating temperature range.
FAQ
What is the primary function of the DS200DMCBG1A board?
This is a Digital Output Processor (DOS DUP) board used in GE Mark V systems to process control logic and manage I/O signals for turbine control applications.
Can this board operate in extreme temperatures?
Yes, the board is rated for an operating temperature range of -40 degC to +70 degC, making it suitable for harsh industrial environments.
