Description
Overview
The GE UR8HH Multilin UR Control Module is a CT/VT processor board designed for the Universal Relay series. Engineers use this module to monitor and protect electrical power systems with precision. Its compact dimensions, modular design, and advanced protection functions make it suitable for industrial, commercial, and utility applications.
Technical Specifications
| Parameter |
Value |
| Model Number |
UR8HH |
| Module Type |
UR Control Module |
| Manufacturer |
GE |
| Product Range |
Multilin |
| Condition |
Brand New |
| Lead Time |
In Stock |
| Weight |
0.84 kg |
| Dimensions |
6 x 19.5 x 17.2 cm |
| HS Code |
8537101190 |
| Minimum Order Quantity |
1 |
| Origin |
USA |
| System |
PLC |
| Status |
Discontinued (Dec 31, 2018) |
| Communication Service |
Ethernet router |
| CT Inputs |
Three 1A/5A phase CTs |
| Ground CTs |
1A/5A |
| Protection Features |
Overcurrent, undervoltage, frequency, differential, ground fault, thermal overload |
| Advanced Functions |
Arc flash protection (configurable) |
Functional Description
The GE UR8HH integrates current and voltage transformer inputs to deliver accurate monitoring and protection. It supports three 1A/5A phase CTs and one 1A/5A ground CT, ensuring precise system measurements. Engineers benefit from comprehensive protection features, including overcurrent, undervoltage, frequency, differential, and ground fault detection.
The GE UR8HH also provides thermal overload protection and configurable arc flash protection, enhancing safety in critical environments. Its modular design allows customization for specific applications, while its rugged construction ensures long-term reliability.
Applications and Compatibility
The GE UR8HH Multilin UR Control Module suits power system applications requiring advanced relay protection and monitoring. It integrates seamlessly with transformers, generators, motors, feeders, and busbars. Professionals rely on the GE UR8HH for flexible deployment in industrial automation, utility networks, and commercial power systems.
