Description
Product Overview
The 750-P5-G5-S5-HI-A20-R-E-H Feeder Management Relay from GE Multilin delivers advanced protection and control for power distribution systems. It features dual microprocessors—Motorola 68332 (32-bit) and Intel 80C186 (16-bit)—for fast and accurate signal processing. This relay supports both primary and backup protection for transformers, buses, and transmission lines.
It operates with a wide input voltage range of 88–300VDC or 70–265VAC and supports frequencies from 48 to 62 Hz. The 750-P5-G5-S5-HI-A20-R-E-H includes 5A phase, zero-sequence, and sensitive ground current inputs. Eight 4–20 mA analog outputs allow real-time control of external devices, while the enhanced display with a “Breaker Closed” LED provides instant system feedback.
Technical Specifications
| Specification |
Details |
| Model Number |
750-P5-G5-S5-HI-A20-R-E-H |
| Module Type |
Feeder Management Relay |
| Product Series |
Multilin |
| Manufacturer |
GE |
| Dimensions |
21.5 × 23 × 25 cm |
| Weight |
7.62 kg |
| Input Voltage Range |
88–300 VDC / 70–265 VAC |
| Frequency Range |
48–62 Hz |
| Processor Architecture |
Motorola 68332 + Intel 80C186 |
| Current Inputs |
5A phase, 5A zero-sequence, 5A ground |
| Analog Outputs |
8 × 4–20 mA |
| Display Features |
Breaker Closed LED |
| Mounting Compatibility |
19-inch rack (SR series) |
| Case Type |
750/760 drawout protection |
| Communication Service |
Ethernet router |
| Compliance |
CE, UL/CUL 508 |
| HS Code |
8537101190 |
| Condition |
Brand New |
| Origin |
USA |
| System Compatibility |
DCS |
| Discontinued Status |
Active |
| Minimum Order Quantity |
1 |
| Lead Time |
In Stock |
Features & Benefits
-
The 750-P5-G5-S5-HI-A20-R-E-H supports dual microprocessors for high-speed signal processing.
-
Wide voltage input range ensures compatibility with diverse power systems.
-
Eight analog outputs enable external device control and system adjustments.
-
LED indicators provide real-time status feedback for operational clarity.
-
Compatible with standard 19-inch racks for seamless integration with SR series relays.
