The IS215WEPAH2BDA and IS200AEPAH1BPH printed circuit board modules are part of GE’s Mark VI and Mark VIe turbine‑control platforms. These boards are designed to acquire, filter, and transmit digital input signals from field devices to the controller, forming a critical link in turbine protection and monitoring systems. Their architecture supports high‑speed signal handling and stable operation in demanding industrial environments.
Functional Characteristics
Both modules are engineered to process real‑time digital inputs used in gas‑turbine, steam‑turbine, and general industrial control applications. They provide reliable signal conditioning and isolation, ensuring that the Mark VI/VIe controller receives accurate and noise‑free data.
The IS215WEPAH2BDA / IS200AEPAH1BPH boards are built to industrial standards, incorporating rugged PCB construction, high‑quality components, and protective coatings suitable for harsh environments. Their fast response times and stable electrical characteristics contribute to precise turbine control and improved system safety.
Mechanical and Electrical Design
Each module is built on a compact PCB measuring 2.1 × 18.8 × 26.2 cm and weighing 0.32 kg. The layout includes clearly labeled connectors, test points, and component identifiers to support efficient installation and maintenance. The boards are designed for long service life with minimal maintenance requirements.
System Integration
These modules integrate directly with Mark VI and Mark VIe control racks and are used for digital‑input acquisition in distributed control architectures. Their compatibility with GE’s turbine‑control ecosystem makes them suitable for both system upgrades and replacement applications.
Technical Specifications
| Parameter |
Specification |
| Models |
IS215WEPAH2BDA, IS200AEPAH1BPH
|
| Product Type |
Printed Circuit Board |
| Brand |
GE |
| Product Range |
Mark VI / Mark VIe |
| Function |
Digital input acquisition and conditioning |
| Construction |
Industrial‑grade PCB |
| Weight |
0.32 kg |
| Dimensions |
2.1 × 18.8 × 26.2 cm |
| HS Code |
8537101190 |
| Minimum Order |
1 unit |
| Origin |
USA |
| Lifecycle Status |
Active |
Application Scenarios
-
Gas and steam turbine digital‑input monitoring
-
Mark VI / Mark VIe distributed control systems
-
Industrial process control requiring high‑speed digital acquisition
-
Harsh‑environment installations requiring durable PCB modules
FAQ
Q: Are these modules interchangeable? A: They belong to the same functional family but may differ in revision level and application specifics; system documentation should be consulted before substitution.
Q: What type of signals do these boards handle? A: They process digital input signals from field devices and transmit conditioned data to the controller.
Q: Are these modules suitable for harsh environments? A: Yes. Their construction meets industrial durability standards for turbine and process‑control applications.
