The IS210BPPBH2BKD Printed Circuit Board is a specialized processing module developed by General Electric for the Mark VIe turbine control platform. Designed as an auxiliary computing board, it expands system capability by providing additional processing resources, diagnostic interfaces, and thermal monitoring functions essential for high‑performance turbine control environments.
Functional Characteristics
This board incorporates a compact processing architecture built around high‑reliability semiconductor components, including an AMD‑based memory device, discrete transistors, precision capacitors, and a temperature‑sensing element with ±2°C accuracy. These components support stable operation across a broad thermal range and ensure dependable data handling within the control system.
The IS210BPPBH2BKD includes multiple diagnostic access points, such as test pads and dual status indicators, enabling technicians to perform rapid troubleshooting and verification. Its mechanical layout features shaped board edges for accurate alignment with the host backplane and four reinforced standoffs for secure mounting.
Connectivity and Integration
-
Two modular communication jacks for system interfacing
-
Vertical multi‑pin connectors for motherboard integration
-
Compatible with Mark VIe HMI environments, including Windows‑based supervisory tools
-
Supports real‑time data acquisition and thermal feedback for turbine protection logic
Mechanical and Environmental Details
-
Dimensions: 29.2 × 13 × 2.7 cm
-
Weight: 0.32 kg
-
Operating temperature: −30°C to +65°C
-
Humidity: 5–95% RH, non‑condensing
-
Designed for continuous operation in vibration‑prone turbine enclosures
Performance and System Role
The board contributes to turbine control reliability by monitoring internal temperature conditions and providing additional processing capability for Mark VIe systems. When temperature thresholds are exceeded, the onboard sensor initiates alarm signaling to prevent equipment damage. Its rugged construction and modular design make it suitable for both new installations and long‑term maintenance programs in power generation facilities.
Applications
-
Gas turbine and steam turbine control systems
-
Mark VIe‑based DCS architectures
-
Auxiliary processing and thermal monitoring
-
High‑reliability industrial control environments
Technical Specifications Table
| Parameter |
Specification |
| Model |
IS210BPPBH2BKD |
| Product Type |
Printed Circuit Board |
| Series |
Mark VIe |
| Processor Components |
AMD memory device, discrete semiconductors |
| Diagnostic Features |
Dual LEDs, multiple test points |
| Connectors |
Modular jacks, vertical system connectors |
| Temperature Sensor Accuracy |
±2°C |
| Dimensions |
29.2 × 13 × 2.7 cm |
| Weight |
0.32 kg |
| Origin |
USA |
| System |
DCS |
| Status |
Active |
FAQ
Q: Is this board a primary controller? A: No. It functions as an auxiliary processing module that supports the main Mark VIe controller.
Q: Does the board include onboard diagnostics? A: Yes. It provides LEDs and test points for field diagnostics and maintenance.
Q: Can this board be used in older Mark VI systems? A: It is designed for Mark VIe platforms; compatibility with earlier systems depends on the specific hardware configuration.
