The IS200TPROH1B Protective Termination Card is a GE Mark VIe field‑termination module engineered to interface protection‑related wiring within turbine control systems. Designed for high‑reliability gas and steam turbine applications, this board provides secure termination points, electrical isolation, and robust surge‑protection features essential for safe turbine operation.
Functional Characteristics
The board includes two high‑density terminal blocks, each offering 24 termination points, enabling reliable connection of trip circuits, protection sensors, and shutdown wiring. Gold‑plated contacts ensure long‑term corrosion resistance and stable signal transmission in high‑vibration turbine enclosures.
The IS200TPROH1B incorporates:
-
Isolation transformers for protection‑signal separation
-
MOV‑based surge suppression for transient overvoltage protection
-
EMI‑filtering components to maintain signal integrity
-
Multiple system connectors for integration with Mark VIe control hardware
Primary connectors (JX1, JY1, JZ1) handle core protection signals, while auxiliary connectors (JX5, JY5, JZ5) support secondary functions and filtered signal paths.
Technical Specifications
| Parameter |
Specification |
| Model |
IS200TPROH1B |
| Product Type |
Protective Termination Card |
| Brand |
GE |
| Series |
Mark VIe |
| Dimensions |
33 × 17.7 × 5 cm |
| Weight |
0.9 kg |
| Origin |
USA |
| HS Code |
8537101190 |
| Condition |
New |
| Availability |
In Stock |
| Termination Points |
48 total (2 × 24‑point blocks) |
| Protection Features |
MOV surge suppression, isolation transformers, EMI filtering |
| Connectors |
JX1/JY1/JZ1 (primary), JX5/JY5/JZ5 (auxiliary) |
| System Compatibility |
DCS / Mark VIe |
| Minimum Order |
1 unit |
Integration and System Role
The IS200TPROH1B is used to:
-
Terminate turbine trip and protection wiring
-
Provide isolated, surge‑protected signal paths
-
Interface shutdown circuits with Mark VIe controllers
-
Maintain stable operation in electrically noisy environments
Its layout and labeling simplify installation and maintenance, reducing downtime during turbine servicing.
Application Scenarios
-
Gas turbine emergency trip systems
-
Steam turbine protection circuits
-
Combined‑cycle plant safety architectures
-
High‑vibration turbine enclosures
-
Mark VIe system upgrades and retrofits
