Description
Overview
The DS200SLCCG4AFG Interface Communication Card is a GE‑engineered module designed for data exchange and signal interfacing within Mark V turbine control systems. It provides a stable communication pathway between control processors, I/O modules, and peripheral devices, supporting real‑time turbine monitoring and coordinated system operation.
Functional Characteristics
This communication card manages digital and analog interface signals, enabling reliable data transfer across the Mark V architecture. Operating from a regulated +5 VDC backplane supply, the DS200SLCCG4AFG maintains low power consumption—typically under 5 watts—making it suitable for dense control racks and thermally constrained environments.
The board is designed to withstand harsh industrial conditions, with an extended operating temperature range and high humidity tolerance. Its circuitry supports multiple I/O formats, allowing flexible integration with various Mark V subsystems.
Electrical and Environmental Performance
| Parameter |
Specification |
| Model |
DS200SLCCG4AFG |
| Product Type |
Interface Communication Card |
| Brand |
GE |
| Series |
Mark V / Mark VIe compatible |
| Dimensions |
18.8 × 4.2 × 2.5 cm |
| Weight |
0.24 kg |
| Origin |
USA |
| HS Code |
8537101190 |
| Condition |
New |
| Availability |
In Stock |
| Power Supply |
+5 VDC (backplane) |
| Power Consumption |
|
| Operating Temperature |
−40°C to +70°C |
| Humidity |
5–95% non‑condensing |
| System Compatibility |
DCS / Mark V |
| Minimum Order |
1 unit |
Integration and System Role
The card supports:
-
Communication between turbine control processors
-
Signal routing for Mark V I/O modules
-
Programming and diagnostic interfaces
-
High‑speed data exchange for real‑time control
Its compact footprint and lightweight construction simplify installation and replacement during maintenance operations.
Application Scenarios
-
Gas and steam turbine control systems
-
Mark V communication backplane integration
-
Industrial automation requiring stable interface modules
-
Retrofit and maintenance of legacy GE control platforms
FAQ
Q: What power source does the module require? A: It operates from a +5 VDC backplane supply.
Q: Is the card suitable for harsh environments? A: Yes. It supports −40°C to +70°C operation and high humidity tolerance.
Q: Does it support both digital and analog communication? A: The card handles multiple I/O formats used within the Mark V system.
