Product Overview
The IS420UCSCH1B Quad Core Controller from GE is built for high-speed, high-reliability industrial control. It runs on QNX® Neutrino, a real-time multitasking OS, and uses hypervisor technology to manage demanding turbine and BoP applications.
This controller supports Predix™ cloud-based and local web applications via secure Embedded Field Agent (EFA) technology. It communicates over IONet, a dedicated Ethernet protocol exclusive to Mark VIe systems. The IEEE 1588 synchronization ensures precise timing across all I/O modules, maintaining ±100 microseconds accuracy.
Unlike traditional controllers, the IS420UCSCH1B does not host I/O on a backplane. Instead, it connects directly to I/O networks, ensuring full data access even during maintenance. This architecture eliminates single points of failure and supports Simplex, Dual, and TMR redundancy.
Technical Specifications
| Specification |
Detail |
| Manufacturer |
GE |
| Part Number |
IS420UCSCH1B |
| System Compatibility |
Mark VIe |
| Voltage |
24 Vdc |
| Current |
1 A |
| Dimensions (cm) |
16.8 × 15.0 × 5.5 |
| Weight |
1.2 kg |
| Processor |
Quad Core |
| Operating System |
QNX® Neutrino |
| Synchronization |
IEEE 1588 (±100 µs) |
| Redundancy Modes |
Simplex, Dual, TMR |
| Expansion Ports |
Up to 7 additional I/O ports |
| Cooling |
Fanless |
| Battery |
None |
| Jumper Settings |
Not required |
| Flash Memory |
Field-upgradable |
Application & Compatibility
The IS420UCSCH1B controller is optimized for Mark VIe systems and supports ControlST V07.01 or later. It is ideal for turbine control, balance of plant operations, and safety-critical industrial automation.
Use this controller in environments requiring real-time data, secure cloud integration, and fault-tolerant redundancy. Its compact design and fanless operation make it suitable for space-constrained installations.
