Product Overview
The GE IS220PVIBH1A Vibration Monitor I/O Pack from the Mark VIe Control Systems series delivers precise vibration and proximity signal acquisition. It supports up to 13 input channels and interfaces directly with the TVBA terminal board using a DC-37 connector.
This module integrates a processor board, acquisition board, and daughterboard, enabling high-speed data capture from sensors like Proximitors®, Velomitor®, accelerometers, and Keyphasor® devices. The unit includes diagnostic LEDs for quick visual status checks.
Technical Specifications
| Specification |
Detail |
| Manufacturer |
General Electric |
| Part Number |
IS220PVIBH1A |
| Series |
Mark VIe Control Systems |
| Voltage Input |
28 Vdc |
| Max Current |
1 A |
| Dimensions (L×W×H) |
8.3 cm × 4.2 cm × 12.2 cm |
| Weight |
340 g |
| Ethernet Ports |
Dual RJ45 |
| Power Input |
3-pin connector |
| Output Connector |
DC-37 pin |
| Channels Supported |
13 total |
Application & Compatibility
The IS220PVIBH1A module is compatible with the TVBA vibration terminal board in both simplex and TMR control modes. It does not support the TVIB board. Frame rates vary depending on network configuration, with dual Ethernet supporting rates below 100 Hz and single Ethernet supporting rates from 3.125 to 100 Hz.
This I/O pack is ideal for turbine vibration monitoring, predictive maintenance systems, and industrial automation requiring high-resolution sensor data.
