Description
The GE IS220PPDAH1B Power Distribution System Feedback I/O Pack is a compact, plug-and-play module designed to monitor and report critical power distribution parameters within the Mark VIe and Mark VIeS control systems. It collects feedback from up to six connected power distribution boards, including bus voltages, branch circuit status, ground fault detection, and bulk power supply health, and transmits this data via a dual redundant Ethernet interface to system controllers.
Technical Specifications
| Parameter |
Specification |
| Manufacturer |
GE |
| Series |
Mark VIe system |
| Part Number |
IS220PPDAH1B |
| Description |
Power Distribution System Feedback I/O Pack |
| Input Voltage |
24 Vdc |
| Current |
1 A |
| Dimensions |
82.6 mm × 41.9 mm × 121 mm |
| Weight |
340 g |
| Input Sources |
Up to 6 power distribution boards |
| Communication |
Dual redundant Ethernet (IONet) |
| Compatibility |
JPDS, JPDM, JPDG, JPDC, JPDB, JPDE, JPDF |
| Configuration |
Plug-and-play with electronic ID recognition |
Key Features
-
Accepts feedback from up to six power distribution boards
-
Monitors power bus voltages, branch circuit status, and ground fault conditions
-
Provides bulk power supply health diagnostics to controllers
-
Dual Ethernet ports ensure redundant communication with Mark VIe/VIeS systems
-
Plug-and-play setup using electronic ID detection and ToolboxST configuration
-
Compact 82.6 × 41.9 × 121 mm form factor for easy integration
-
Lightweight 340 g design supports flexible mounting options
