Description

Overview

The IS215ACLEH1B Application Control Layer Module from GE’s EX2100 Excitation Control system functions as a high-performance master controller. It manages communication across Ethernet and ISBus networks and mounts in either Innovation Series drives or exciter board racks.

Technical Specifications

Specification	Detail
Manufacturer	GE
Model Number	IS215ACLEH1B
Product Series	EX2100 Excitation Control System
Function	Master controller for networked systems
Voltage	28 Vdc
Current	2 A
Dimensions	18 cm × 12 cm × 5 cm
Weight	0.5 kg
Memory	8 MB DRAM, 4 MB flash BIOS
Cache	128 KB level 2
Interfaces	Ethernet, ISBus, COM1, COM2
Connector Type	128-pin P1
Mounting Location	CABP or EBKP backplane
Slot Occupancy	Two half-slots

Specifications

• Dimensions: 18 cm × 12 cm × 5 cm
• Brand: GE

Advantages

• High reliability in industrial environments
• Supports continuous operation
• Compatible with major PLC/DCS systems
