GE IS210TREAS1A Turbine Remote Emergency Trip Board

The GE IS210TREAS1A, also cataloged as the IS210TREA Turbine Remote Emergency Trip Board, operates as a dedicated hardware component for emergency shutdown signal execution within GE Mark VIe Turbine Control Systems. The board processes trip commands and drives relay outputs for turbine protection circuits with deterministic response behavior.

Hardware Specifications

Parameter	Specification
Model	IS210TREAS1A
Brand	GE
Origin	United States
Weight	2.00 lbs
Operating Temp	-30 to +65 deg C
Power Consumption	28 VDC nominal from Mark VIe backplane
Product Type	Aero Derivative Turbine Emergency Trip Board
System Platform	GE Mark VIe Turbine Control System
Functional Acronym	TREA
Function	Emergency Trip Terminal Board
Inputs	6 trip command inputs
Outputs	3 trip relay outputs
Relay Type	Electromechanical, normally energized
Response Time	< 10 ms
Isolation	2500 Vrms channel-to-ground
PCB Coating Type	S-style conformal coating
Technology	Surface Mount
Assembly Type	IS210 Special Assembly

Profinet / EtherNet-IP Deterministic Networks and Firmware Compatibility

The IS210TREAS1A operates as a protection interface component within the Mark VIe control architecture, executing hardware-based emergency trip logic through defined input and relay output paths. The board supports deterministic trip signal handling by maintaining direct electrical interfaces between controller commands, protection inputs, and shutdown circuits.

The module design follows GE industrial control hardware practices with firmware and configuration compatibility managed through the Mark VIe engineering environment. The conformal-coated PCB assembly provides additional protection for electronic circuits exposed to industrial cabinet conditions.

Frequently Asked Questions

Q: What is the primary switching function of the IS210TREAS1A?
A: The board receives turbine trip command signals and actuates relay outputs connected to turbine shutdown circuits.

Q: How many field signal channels are provided by the IS210TREAS1A?
A: The board provides 6 trip command inputs and 3 relay output channels.

Q: Does the board provide electrical isolation for trip circuits?
A: The IS210TREAS1A provides channel-to-ground isolation rated at 2500 Vrms.

Field Installation Guidelines

Verify cabinet power isolation before installing or removing the board. Use ESD protection when handling the PCB assembly. Install the board into the designated Mark VIe I/O rack position and confirm connector engagement.

Wire trip command inputs according to the configured protection logic. Route relay output wiring separately from high-current switching conductors. Apply appropriate cable shielding and grounding practices to reduce electrical interference and prevent unintended trip signals.

Verify relay operation, input status, and diagnostic feedback through ToolboxST software before returning the turbine control system to service.
