Description

Product Overview

The IS200VTCCH1CBD Thermocouple Processor Board from General Electric belongs to the EX2100 range and supports advanced turbine control systems. This module weighs 0.3 kg and measures 2 x 18.8 x 26.1 cm, making it compact yet powerful. Engineers rely on its robust design, precise input handling, and reliable energy storage components.

Technical Specifications

Parameter	Value
Model Number	IS200VTCCH1CBD
Module Type	Thermocouple Processor Board
Manufacturer	GE
Product Range	EX2100
Condition	Brand New
Weight	0.3 kg
Dimensions	2 x 18.8 x 26.1 cm
HS Code	8537101190
Minimum Order Quantity	1
Origin	USA
System	DCS
Status	Active
Communication Service	Ethernet router

Functional Description

The IS200VTCCH1CBD board processes up to twenty-four thermocouple inputs through TBTC and DTTC terminal boards. It supports thermocouple types T, S, K, J, and E, with mV input ranges from -8mV to +45mV. Engineers cannot connect types B, N, or R, as those require a VTCCH2 board.

This module integrates two backplanes and four conductive connectors. Hundreds of capacitors, resistors, diodes, inductors, and test points ensure stable operation. Integrated circuits include dual-port SRAM, FPGAs, CMOS static RAM, and digital signal processors, delivering high-speed data handling.

The front faceplate features three LED indicators: green Run, red Fail, and orange Status. These provide immediate feedback on system performance.

Specifications

• Dimensions: 2 x 18.8 x 26.1 cm
• Brand: General Electric

Advantages

• High reliability in industrial environments
• Supports continuous operation
• Compatible with major PLC/DCS systems
