Description

Overview

The IS200TSVCH1A Servo Input/Output Terminal Board from GE’s Mark VIe series delivers precise control for turbine valve positioning. It supports two bi-directional servo current output channels, each with LVDT excitation, LVDT feedback, and pulse rate inputs for fuel flow monitoring.

Technical Specifications

Specification	Detail
Manufacturer	GE
Model Number	IS200TSVCH1A
Product Series	Mark VIe
Function	Servo I/O with LVDT feedback
Voltage	24 Vdc
Current	1 A
Dimensions	33.02 cm × 17.8 cm × 2.3 cm
Weight	0.3 kg
Servo Channels	2
LVDT Inputs	Up to 8
Pulse Rate Inputs	2
Cable Length Support	Up to 300 m
Max Cable Resistance	15 Ω
Coil Configurations	1–3 coil (simplex/TMR)
Relay Type	Suicide relay with manual reset

Specifications

• Dimensions: 33.02 cm × 17.8 cm × 2.3 cm
• Brand: GE

Advantages

• High reliability in industrial environments
• Supports continuous operation
• Compatible with major PLC/DCS systems
